4GHL | pdb_00004ghl

Structural Basis for Marburg virus VP35 mediate immune evasion mechanisms


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.02 Å
  • R-Value Free:
    0.240 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.187 (Depositor), 0.187 (DCC)
  • R-Value Observed:
    0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4GHL

This is version 1.2 of the entry. See complete history

Literature

Structural basis for Marburg virus VP35-mediated immune evasion mechanisms.

Ramanan, P.Edwards, M.R.Shabman, R.S.Leung, D.W.Endlich-Frazier, A.C.Borek, D.M.Otwinowski, Z.Liu, G.Huh, J.Basler, C.F.Amarasinghe, G.K.

(2012) Proc Natl Acad Sci U S A 109: 20661-20666

  • DOI: https://doi.org/10.1073/pnas.1213559109
  • Primary Citation Related Structures:
    4GHL

  • PubMed Abstract:

    Filoviruses, marburgvirus (MARV) and ebolavirus (EBOV), are causative agents of highly lethal hemorrhagic fever in humans. MARV and EBOV share a common genome organization but show important differences in replication complex formation, cell entry, host tropism, transcriptional regulation, and immune evasion. Multifunctional filoviral viral protein (VP) 35 proteins inhibit innate immune responses. Recent studies suggest double-stranded (ds)RNA sequestration is a potential mechanism that allows EBOV VP35 to antagonize retinoic-acid inducible gene-I (RIG-I) like receptors (RLRs) that are activated by viral pathogen-associated molecular patterns (PAMPs), such as double-strandedness and dsRNA blunt ends. Here, we show that MARV VP35 can inhibit IFN production at multiple steps in the signaling pathways downstream of RLRs. The crystal structure of MARV VP35 IID in complex with 18-bp dsRNA reveals that despite the similar protein fold as EBOV VP35 IID, MARV VP35 IID interacts with the dsRNA backbone and not with blunt ends. Functional studies show that MARV VP35 can inhibit dsRNA-dependent RLR activation and interferon (IFN) regulatory factor 3 (IRF3) phosphorylation by IFN kinases TRAF family member-associated NFkb activator (TANK) binding kinase-1 (TBK-1) and IFN kB kinase e (IKKe) in cell-based studies. We also show that MARV VP35 can only inhibit RIG-I and melanoma differentiation associated gene 5 (MDA5) activation by double strandedness of RNA PAMPs (coating backbone) but is unable to inhibit activation of RLRs by dsRNA blunt ends (end capping). In contrast, EBOV VP35 can inhibit activation by both PAMPs. Insights on differential PAMP recognition and inhibition of IFN induction by a similar filoviral VP35 fold, as shown here, reveal the structural and functional plasticity of a highly conserved virulence factor.


  • Organizational Affiliation
    • Department of Pathology and Immunology, Washington University School of Medicine, St. Louis, MO 63110, USA.

Macromolecule Content

  • Total Structure Weight: 70.68 kDa
  • Atom Count: 5,048
  • Modeled Residue Count: 534
  • Deposited Residue Count: 568
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Polymerase cofactor VP35C [auth A],
D [auth B],
E [auth C],
F [auth D]
133Lake Victoria marburgvirus - PoppMutation(s): 1
Gene Names: Polymerase cofactor VP35VP35
UniProt
Find proteins for Q03039 (Lake Victoria marburgvirus (strain Popp-67))
Explore Q03039
Go to UniProtKB:  Q03039
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03039
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
short palindromic RNA AGACAGCAUAUGCUGUCUA [auth E],
B [auth F]
18N/A
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
EDO

Query on EDO



Download:Ideal Coordinates CCD File
N [auth A],
O [auth A],
T [auth B],
X [auth C]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
Q [auth B],
R [auth B],
S [auth B],
W [auth C]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG

Query on MG



Download:Ideal Coordinates CCD File
G [auth E]
H [auth E]
I [auth E]
J [auth F]
K [auth F]
G [auth E],
H [auth E],
I [auth E],
J [auth F],
K [auth F],
L [auth F],
M [auth A],
P [auth B],
U [auth C],
V [auth C],
Y [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.02 Å
  • R-Value Free:  0.240 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.187 (Depositor), 0.187 (DCC)
  • R-Value Observed: 0.190 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 83.771α = 90
b = 93.384β = 90
c = 102.071γ = 90
Software Package:
Software NamePurpose
HKL-3000data collection
MOLREPphasing
REFMACrefinement
HKL-3000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-11-28
    Type: Initial release
  • Version 1.1: 2012-12-26
    Changes: Database references
  • Version 1.2: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
