4FS7 | pdb_00004fs7

Crystal structure of a leucine-rich repeat protein (BACOVA_04585) from Bacteroides ovatus ATCC 8483 at 1.19 A resolution

PDB DOI: https://doi.org/10.2210/pdb4FS7/pdb

Classification: PROTEIN BINDING
Organism(s): Bacteroides ovatus ATCC 8483
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-06-27 Released: 2012-09-19
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free:
0.157 (Depositor), 0.157 (DCC)
R-Value Work:
0.131 (Depositor), 0.131 (DCC)
R-Value Observed:
0.132 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4FS7

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a hypothetical leucine rich repeat protein (BACOVA_04585) from Bacteroides ovatus ATCC 8483 at 1.19 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 44.43 kDa
Atom Count: 3,837
Modeled Residue Count: 383
Deposited Residue Count: 394
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	394	Bacteroides ovatus ATCC 8483	Mutation(s): 0 Gene Names: BACOVA_04585

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free: 0.157 (Depositor), 0.157 (DCC)
R-Value Work: 0.131 (Depositor), 0.131 (DCC)
R-Value Observed: 0.132 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.199	α = 90
b = 84.416	β = 90
c = 121.937	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-09-19

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2012-09-19
Type: Initial release
Version 1.1: 2014-12-24
Changes: Structure summary
Version 1.2: 2017-11-15
Changes: Refinement description
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-20
Changes: Data collection, Structure summary
