4EP0

Structure of the bacteriophage C1 tail knob protein, gp12


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.195
  • R-Value Observed: 0.197

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural investigations of a Podoviridae streptococcus phage C1, implications for the mechanism of viral entry.

Aksyuk, A.A.Bowman, V.D.Kaufmann, B.Fields, C.Klose, T.Holdaway, H.A.Fischetti, V.A.Rossmann, M.G.

(2012) Proc Natl Acad Sci U S A 109: 14001-14006

  • DOI: https://doi.org/10.1073/pnas.1207730109
  • Primary Citation of Related Structures:
    4EO2, 4EP0

  • PubMed Abstract:

    The Podoviridae phage C1 was one of the earliest isolated bacteriophages and the first virus documented to be active against streptococci. The icosahedral and asymmetric reconstructions of the virus were calculated using cryo-electron microscopy. The capsid protein has an HK97 fold arranged into a T = 4 icosahedral lattice. The C1 tail is terminated with a ϕ29-like knob, surrounded by a skirt of twelve long appendages with novel morphology. Several C1 structural proteins have been identified, including a candidate for an appendage. The crystal structure of the knob has an N-terminal domain with a fold observed previously in tube forming proteins of Siphoviridae and Myoviridae phages. The structure of C1 suggests the mechanisms by which the virus digests the cell wall and ejects its genome. Although there is little sequence similarity to other phages, conservation of the structural proteins demonstrates a common origin of the head and tail, but more recent evolution of the appendages.


  • Organizational Affiliation

    Department of Biological Sciences, Purdue University, West Lafayette, IN 47907-2032, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Major tail protein
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J, K, L
583Fischettivirus C1Mutation(s): 0
Gene Names: orf12
UniProt
Find proteins for Q7Y3F0 (Streptococcus phage C1)
Explore Q7Y3F0
Go to UniProtKB:  Q7Y3F0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Y3F0
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.195
  • R-Value Observed: 0.197
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 316.868α = 90
b = 211.38β = 116.53
c = 178.605γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHASERphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-08-22
    Type: Initial release
  • Version 1.1: 2012-08-29
    Changes: Database references
  • Version 1.2: 2012-09-12
    Changes: Database references
  • Version 1.3: 2023-09-13
    Changes: Data collection, Database references, Refinement description
