 4DWL | pdb_00004dwl

Avd molecule from Bordetella bacteriophage DGR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:
    0.244 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.194 (Depositor), 0.191 (DCC)
  • R-Value Observed:
    0.197 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4DWL

This is version 1.2 of the entry. See complete history.

Literature

Structure of the essential diversity-generating retroelement protein bAvd and its functionally important interaction with reverse transcriptase.

Alayyoubi, M., Guo, H., Dey, S., Golnazarian, T., Brooks, G.A., Rong, A., Miller, J.F., Ghosh, P.

(2013) Structure 21: 266-276

  • DOI: https://doi.org/10.1016/j.str.2012.11.016
  • Primary Citation Related Structures:
    4DWL

  • PubMed Abstract:

    Diversity-generating retroelements (DGRs) are the only known source of massive protein sequence variation in prokaryotes. These elements transfer coding information from a template region (TR) through an RNA intermediate to a protein-encoding variable region. This retrohoming process is accompanied by unique adenine-specific mutagenesis and, in the prototypical BPP-1 DGR, requires a reverse transcriptase (bRT) and an accessory variability determinant (bAvd) protein. To understand the role of bAvd, we determined its 2.69 Å resolution structure, which revealed a highly positively charged pentameric barrel. In accordance with its charge, bAvd bound both DNA and RNA, albeit without a discernable sequence preference. We found that the coding sequence of bAvd functioned as part of TR but identified means to mutate bAvd without affecting TR. This mutational analysis revealed a strict correspondence between retrohoming and interaction of bAvd with bRT, suggesting that the bRT-bAvd complex is important for DGR retrohoming.


  • Organizational Affiliation:
    • Department of Chemistry and Biochemistry, University of California, San Diego, La Jolla, CA 92093, USA.

Macromolecule Content

  • Total Structure Weight: 75.14 kDa
  • Atom Count: 4,394
  • Modeled Residue Count: 545
  • Deposited Residue Count: 655
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Bbp7A,
B,
C [auth E],
D [auth C],
E [auth D]
131Rauchvirus BPP1Mutation(s): 0
Gene Names: bbp7
UniProt
Find proteins for Q775D7 (Bordetella phage BPP-1)
Explore Q775D7
Go to UniProtKB:  Q775D7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ775D7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PO4

Query on PO4



Download:Ideal Coordinates CCD File
F [auth A]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Modified Residues  1 Unique
IDChains Modified ResidueModification TypeFormula2D Diagram
MSE
Query on MSE
METSelenomethionineC5 H11 N O2 Se

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:  0.244 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.194 (Depositor), 0.191 (DCC)
  • R-Value Observed: 0.197 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.317α = 90
b = 63.072β = 103.77
c = 105.295γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SOLVEphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-02-27
    Type: Initial release
  • Version 1.1: 2015-01-14
    Changes: Database references
  • Version 1.2: 2024-11-06
    Changes: Data collection, Database references, Derived calculations, Structure summary
