4B6Z | pdb_00004b6z

Crystal structure of metallo-carboxypeptidase from Burkholderia cenocepacia


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.205 (Depositor), 0.205 (DCC)
  • R-Value Work:
    0.164 (Depositor), 0.165 (DCC)
  • R-Value Observed:
    0.166 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4B6Z

This is version 1.3 of the entry. See complete history

Literature

High-Resolution Structure of the M14-Type Cytosolic Carboxypeptidase from Burkholderia Cenocepacia Refined Exploiting Pdb_Redo Strategies.

Rimsa, V.Eadsforth, T.C.Joosten, R.P.Hunter, W.N.

(2014) Acta Crystallogr D Biol Crystallogr 70: 279

  • DOI: https://doi.org/10.1107/S1399004713026801
  • Primary Citation Related Structures:
    4B6Z

  • PubMed Abstract:

    A potential cytosolic metallocarboxypeptidase from Burkholderia cenocepacia has been crystallized and a synchrotron-radiation microfocus beamline allowed the acquisition of diffraction data to 1.9 Å resolution. The asymmetric unit comprises a tetramer containing over 1500 amino acids, and the high-throughput automated protocols embedded in PDB_REDO were coupled with model-map inspections in refinement. This approach has highlighted the value of such protocols for efficient analyses. The subunit is constructed from two domains. The N-terminal domain has previously only been observed in cytosolic carboxypeptidase (CCP) proteins. The C-terminal domain, which carries the Zn2+-containing active site, serves to classify this protein as a member of the M14D subfamily of carboxypeptidases. Although eukaryotic CCPs possess deglutamylase activity and are implicated in processing modified tubulin, the function and substrates of the bacterial family members remain unknown. The B. cenocepacia protein did not display deglutamylase activity towards a furylacryloyl glutamate derivative, a potential substrate. Residues previously shown to coordinate the divalent cation and that contribute to peptide-bond cleavage in related enzymes such as bovine carboxypeptidase are conserved. The location of a conserved basic patch in the active site adjacent to the catalytic Zn2+, where an acetate ion is identified, suggests recognition of the carboxy-terminus in a similar fashion to other carboxypeptidases. However, there are significant differences that indicate the recognition of substrates with different properties. Of note is the presence of a lysine in the S1' recognition subsite that suggests specificity towards an acidic substrate.


  • Organizational Affiliation
    • Division of Biological Chemistry and Drug Discovery, College of Life Sciences, University of Dundee, Dundee DD1 5EH, Scotland.

Macromolecule Content

  • Total Structure Weight: 182.76 kDa
  • Atom Count: 13,485
  • Modeled Residue Count: 1,518
  • Deposited Residue Count: 1,620
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
FAMILY M14 UNASSIGNED PEPTIDASE
A, B, C, D
405Burkholderia cenocepaciaMutation(s): 7
UniProt
Find proteins for B4EEQ5 (Burkholderia cenocepacia (strain ATCC BAA-245 / DSM 16553 / LMG 16656 / NCTC 13227 / J2315 / CF5610))
Explore B4EEQ5
Go to UniProtKB:  B4EEQ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB4EEQ5
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PEG

Query on PEG



Download:Ideal Coordinates CCD File
DA [auth D]DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
AA [auth D]
F [auth A]
G [auth A]
H [auth A]
K [auth B]
AA [auth D],
F [auth A],
G [auth A],
H [auth A],
K [auth B],
L [auth B],
S [auth C],
Y [auth D],
Z [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
E [auth A],
J [auth B],
Q [auth C],
X [auth D]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
BA [auth D]
CA [auth D]
M [auth B]
N [auth B]
R [auth C]
BA [auth D],
CA [auth D],
M [auth B],
N [auth B],
R [auth C],
T [auth C],
U [auth C]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT

Query on ACT



Download:Ideal Coordinates CCD File
EA [auth D],
I [auth A],
P [auth B],
W [auth C]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
CL

Query on CL



Download:Ideal Coordinates CCD File
FA [auth D],
O [auth B],
V [auth C]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.205 (Depositor), 0.205 (DCC)
  • R-Value Work:  0.164 (Depositor), 0.165 (DCC)
  • R-Value Observed: 0.166 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.897α = 90
b = 85.947β = 90
c = 289.016γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
iMOSFLMdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-03-27
    Type: Initial release
  • Version 1.1: 2014-02-12
    Changes: Database references
  • Version 1.2: 2014-02-26
    Changes: Database references
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
