43SK | pdb_000043sk

Crystal structure of H2-Q9/VP2.139 peptide H1A mutant

PDB DOI: https://doi.org/10.2210/pdb43SK/pdb

Classification: IMMUNE SYSTEM
Organism(s): Mus musculus, Alphapolyomavirus muris
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2026-07-15 Released: 2026-07-22
Deposition Author(s): Tennant, L., Jobichen, C., Tran, M.T., Littler, D.R., Farenc, C., Gras, S., Lukacher, A.E., Sullivan, L.C., Brooks, A.G., Rossjohn, J.
Funding Organization(s): Australian Research Council (ARC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free:
0.246 (Depositor), 0.249 (DCC)
R-Value Work:
0.209 (Depositor), 0.211 (DCC)
R-Value Observed:
0.211 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 43SK

This is version 1.0 of the entry. See complete history.

Literature

A murine MHC-Ib molecule, H2-Q9, drives peptide-centric T cell receptor recognition of a viral antigen

Tennant, L., Jobichen, C., Tran, M.T., Littler, D.R., Farenc, C., Gras, S., Lukacher, A.E., Sullivan, L.C., Brooks, A.G., Rossjohn, J.

To be published.

Macromolecule Content

Total Structure Weight: 44.83 kDa
Atom Count: 3,266
Modeled Residue Count: 384
Deposited Residue Count: 386
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histocompatibility 2, Q region locus 7	A	277	Mus musculus	Mutation(s): 0 Gene Names: H2-Q9, H2-Q7
UniProt
Find proteins for Q52PG7 (Mus musculus) Explore Q52PG7 Go to UniProtKB: Q52PG7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q52PG7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	B	100	Mus musculus	Mutation(s): 1 Gene Names: B2m
UniProt & NIH Common Fund Data Resources
Find proteins for P01887 (Mus musculus) Explore P01887 Go to UniProtKB: P01887
IMPC: MGI:88127
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01887
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Minor capsid protein VP2	C [auth P]	9	Alphapolyomavirus muris	Mutation(s): 1
UniProt
Find proteins for P03097 (Murine polyomavirus (strain A3)) Explore P03097 Go to UniProtKB: P03097
Entity Groups
UniProt Group	P03097
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free: 0.246 (Depositor), 0.249 (DCC)
R-Value Work: 0.209 (Depositor), 0.211 (DCC)
R-Value Observed: 0.211 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.619	α = 90
b = 56.799	β = 90
c = 119.314	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	--

Revision History (Full details and data files)

Version 1.0: 2026-07-22
Type: Initial release
