43FX | pdb_000043fx

Deposited: 2026-06-30 Released: 2026-09-02
Deposition Author(s): Wu, F., Gao, S., Zhang, L.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Wu, F., Gao, S., Zhang, L.

To be published.

Macromolecule Content

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Decaprenylphosphoryl-beta-D-ribose oxidase	A, C [auth B]	461	Mycobacterium tuberculosis H37Rv	Mutation(s): 0 Gene Names: dprE1, Rv3790 EC: 1.1.98.3
UniProt
Find proteins for P9WJF1 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WJF1 Go to UniProtKB: P9WJF1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WJF1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Decaprenylphosphoryl-2-keto-beta-D-erythro-pentose reductase	B [auth C], D	254	Mycobacterium tuberculosis H37Rv	Mutation(s): 0 Gene Names: dprE2, Rv3791, MTCY13D12.25 EC: 1.1.1.333
UniProt
Find proteins for P9WGS9 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WGS9 Go to UniProtKB: P9WGS9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WGS9
Sequence Annotations Expand
Reference Sequence

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD (Subject of Investigation/LOI) Query on FAD Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth B] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B]	E [auth A], G [auth B]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain E [auth A] Focus chain G [auth B] Interactions & Density Focus chain E [auth A] Focus chain G [auth B]
A1L5L( Subject of Investigation/LOI) Query on A1L5L Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain H [auth B] MOL2 format, chain F [auth A] MOL2 format, chain H [auth B] mmCIF format, chain F [auth A] mmCIF format, chain H [auth B]	F [auth A], H [auth B]	quabodepistat C₂₁ H₂₀ Cl F₃ N₂ O₄ XZISSTDXPBUCJA-DYESRHJHSA-N		Interactions Focus chain F [auth A] Focus chain H [auth B] Interactions & Density Focus chain F [auth A] Focus chain H [auth B]
