3WDJ | pdb_00003wdj

Crystal structure of Pullulanase complexed with maltotetraose from Anoxybacillus sp. LM18-11

PDB DOI: https://doi.org/10.2210/pdb3WDJ/pdb

Classification: HYDROLASE
Organism(s): Anoxybacillus sp. LM18-11
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-06-18 Released: 2014-04-30
Deposition Author(s): Xu, J., Ren, F., Huang, C.H., Zheng, Y., Zhen, J., Ko, T.P., Chen, C.C., Chan, H.C., Guo, R.T., Ma, Y., Song, H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.22 Å
R-Value Free:
0.217 (Depositor), 0.227 (DCC)
R-Value Work:
0.181 (Depositor), 0.198 (DCC)
R-Value Observed:
0.181 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Cloning, Expression, Functional and Structural Studies of Pullulanase from Anoxybacillus sp. LM18-11

Xu, J., Ren, F., Huang, C.H., Zheng, Y., Zhen, J., Chen, C.C., Chan, H.C., Guo, R.T., Ma, Y., Song, H.

To be published.

Macromolecule Content

Total Structure Weight: 84.88 kDa
Atom Count: 6,412
Modeled Residue Count: 683
Deposited Residue Count: 710
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Type I pullulanase	A	710	Anoxybacillus sp. LM18-11	Mutation(s): 0 Gene Names: pulA EC: 3.2.1.41
UniProt
Find proteins for K9L0H1 (Anoxybacillus sp. LM18-11) Explore K9L0H1 Go to UniProtKB: K9L0H1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	K9L0H1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose	B, C, D, E	4		N/A	Interactions Focus chain B Focus chain C Focus chain D Focus chain E Interactions & Density Focus chain B Focus chain C Focus chain D Focus chain E
Glycosylation Resources
GlyTouCan: G87171PZ GlyCosmos: G87171PZ GlyGen: G87171PZ

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900010 Query on PRD_900010	B, C, D, E	alpha-maltotetraose	Oligosaccharide / Substrate analog		Interactions Focus chain B Focus chain C Focus chain D Focus chain E Interactions & Density Focus chain B Focus chain C Focus chain D Focus chain E

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.22 Å
R-Value Free: 0.217 (Depositor), 0.227 (DCC)
R-Value Work: 0.181 (Depositor), 0.198 (DCC)
R-Value Observed: 0.181 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 139.971	α = 90
b = 65.929	β = 90
c = 90.921	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHASER	phasing
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-04-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-04-30
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Database references, Derived calculations, Non-polymer description, Structure summary
Version 2.1: 2023-11-08
Changes: Data collection, Database references, Refinement description, Structure summary
