3VMY | pdb_00003vmy

Crystal Structure of a parallel coiled-coil dimerization domain from the voltage-gated proton channel (REDUCTION/DTT)

PDB DOI: https://doi.org/10.2210/pdb3VMY/pdb

Classification: MEMBRANE PROTEIN
Organism(s): Mus musculus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-12-19 Released: 2013-01-30
Deposition Author(s): Fujiwara, Y., Takeshita, K., Kobayashi, M., Okamura, Y., Nakagawa, A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.47 Å
R-Value Free:
0.234 (Depositor), 0.251 (DCC)
R-Value Work:
0.198 (Depositor), 0.217 (DCC)
R-Value Observed:
0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3VMY

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of a Parallel Coiled-Coil Dimerization Domain from the Voltage-Gated Proton Channel (Reduction/Dtt)

Fujiwara, Y., Takeshita, K., Kobayashi, M., Okamura, Y., Nakagawa, A.

To be published.

Macromolecule Content

Total Structure Weight: 23.71 kDa
Atom Count: 1,942
Modeled Residue Count: 191
Deposited Residue Count: 204
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Voltage-gated hydrogen channel 1	A, B [auth C], C [auth B], D	51	Mus musculus	Mutation(s): 0 Gene Names: Bts, Hvcn1, Vsop
UniProt
Find proteins for Q3U2S8 (Mus musculus) Explore Q3U2S8 Go to UniProtKB: Q3U2S8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q3U2S8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.47 Å
R-Value Free: 0.234 (Depositor), 0.251 (DCC)
R-Value Work: 0.198 (Depositor), 0.217 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.165	α = 90
b = 54.068	β = 90
c = 81.54	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-01-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-01-30
Type: Initial release
Version 1.1: 2017-11-22
Changes: Refinement description
Version 1.2: 2023-11-08
Changes: Data collection, Database references, Refinement description
