3UZQ | pdb_00003uzq

Crystal structure of the dengue virus serotype 1 envelope protein domain III in complex with the variable domains of Mab 4E11


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.188 (Depositor), 0.184 (DCC)
  • R-Value Work:
    0.176 (Depositor), 0.173 (DCC)
  • R-Value Observed:
    0.177 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3UZQ

This is version 1.3 of the entry. See complete history

Literature

Mechanism of dengue virus broad cross-neutralization by a monoclonal antibody.

Cockburn, J.J.Navarro Sanchez, M.E.Fretes, N.Urvoas, A.Staropoli, I.Kikuti, C.M.Coffey, L.L.Arenzana Seisdedos, F.Bedouelle, H.Rey, F.A.

(2012) Structure 20: 303-314

  • DOI: https://doi.org/10.1016/j.str.2012.01.001
  • Primary Citation Related Structures:
    3UYP, 3UZE, 3UZQ, 3UZV

  • PubMed Abstract:

    The dengue virus (DENV) complex is composed of four distinct but serologically related flaviviruses, which together cause the present-day most important emerging viral disease. Although DENV infection induces lifelong immunity against viruses of the same serotype, the antibodies raised appear to contribute to severe disease in cases of heterotypic infections. Understanding the mechanisms of DENV neutralization by antibodies is, therefore, crucial for the design of vaccines that simultaneously protect against all four viruses. Here, we report a comparative, high-resolution crystallographic analysis of an "A-strand" murine monoclonal antibody, Mab 4E11, in complex with its target domain of the envelope protein from the four DENVs. Mab 4E11 is capable of neutralizing all four serotypes, and our study reveals the determinants of this cross-reactivity. The structures also highlight the mechanism by which A-strand Mabs disrupt the architecture of the mature virion, inducing premature fusion loop exposure and concomitant particle inactivation.


  • Organizational Affiliation
    • Unité de Virologie Structurale, Département de Virologie, Institut Pasteur, 75724 Paris Cedex 15, France.

Macromolecule Content

  • Total Structure Weight: 40.66 kDa
  • Atom Count: 2,915
  • Modeled Residue Count: 329
  • Deposited Residue Count: 367
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
anti-dengue Mab 4E11253Mus musculusMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
envelope protein114dengue virus type 1Mutation(s): 0
UniProt
Find proteins for P27909 (Dengue virus type 1 (strain Brazil/97-11/1997))
Explore P27909
Go to UniProtKB:  P27909
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP27909
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MES

Query on MES



Download:Ideal Coordinates CCD File
J [auth A]2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
C [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
H [auth A]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
K [auth A],
L [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.188 (Depositor), 0.184 (DCC)
  • R-Value Work:  0.176 (Depositor), 0.173 (DCC)
  • R-Value Observed: 0.177 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 110.71α = 90
b = 110.71β = 90
c = 58.32γ = 120
Software Package:
Software NamePurpose
SCALEPACKdata scaling
BUSTER-TNTrefinement
PDB_EXTRACTdata extraction
XDSdata scaling
XDSdata reduction
PHASERphasing
BUSTERrefinement

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2012-02-22
    Type: Initial release
  • Version 1.1: 2012-04-18
    Changes: Database references
  • Version 1.2: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2024-11-06
    Changes: Structure summary
