3TZ7 | pdb_00003tz7

Kinase domain of cSrc in complex with RL103

PDB DOI: https://doi.org/10.2210/pdb3TZ7/pdb

Classification: TRANSFERASE/TRANSFERASE INHIBITOR
Organism(s): Gallus gallus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2011-09-27 Released: 2012-10-10
Deposition Author(s): Gruetter, C., Richters, A., Rauh, D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.30 Å
R-Value Free:
0.256 (Depositor), 0.246 (DCC)
R-Value Work:
0.189 (Depositor), 0.185 (DCC)
R-Value Observed:
0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3TZ7

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Overcoming Gatekeeper Mutations in cSrc and Abl by Hybrid Compound Design

Richters, A., Getlik, M., Gruetter, C., Schneider, R., Heuckmann, J.M., Heynck, S., Sos, M.L., Thomas, R.K., Rauh, D.

To be published.

Macromolecule Content

Total Structure Weight: 66.73 kDa
Atom Count: 4,282
Modeled Residue Count: 520
Deposited Residue Count: 572
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Proto-oncogene tyrosine-protein kinase Src	A, B	286	Gallus gallus	Mutation(s): 1 Gene Names: SRC, v-Src sarcoma viral oncogene EC: 2.7.10.2
UniProt
Find proteins for P00523 (Gallus gallus) Explore P00523 Go to UniProtKB: P00523
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P00523
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AQB Query on AQB Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	N-(4-{[4-({[1-(3-aminophenyl)-3-tert-butyl-1H-pyrazol-5-yl]carbamoyl}amino)phenyl]amino}quinazolin-6-yl)-4-(dimethylamino)butanamide C₃₄ H₄₀ N₁₀ O₂ WIVSUJLYDAGUDC-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.30 Å
R-Value Free: 0.256 (Depositor), 0.246 (DCC)
R-Value Work: 0.189 (Depositor), 0.185 (DCC)
R-Value Observed: 0.193 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.55	α = 79.28
b = 64.28	β = 87.38
c = 75.4	γ = 90.2

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MAR345dtb	data collection
XDS	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-10-10

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2012-10-10
Type: Initial release
Version 1.1: 2023-11-01
Changes: Data collection, Database references, Derived calculations, Refinement description
