3TN5 | pdb_00003tn5

Crystal structure of GkaP mutant Y99L from Geobacillus kaustophilus HTA426

• PDB DOI: https://doi.org/10.2210/pdb3TN5/pdb

• Classification: HYDROLASE
• Organism(s): Geobacillus kaustophilus HTA426
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2011-09-01 Released: 2012-09-12
• Deposition Author(s): An, J., Zhang, Z., Zhang, Y., Feng, Y., Wu, G.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:
  0.249 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.222 (Depositor), 0.222 (DCC)

Literature

Engineering a thermostable lactonase for enhanced phosphotriesterase activity against organophosphate pesticides

An, J., Zhang, Z., Zhang, Y., Feng, Y., Wu, G.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 80.3 kDa
• Atom Count: 5,597
• Modeled Residue Count: 648
• Deposited Residue Count: 720
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphotriesterase	A, B	360	Geobacillus kaustophilus HTA426	Mutation(s): 1  Gene Names: GK1506 EC: 3.5
UniProt
Find proteins for Q5KZU5 (Geobacillus kaustophilus (strain HTA426)) Explore Q5KZU5  Go to UniProtKB:  Q5KZU5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	G [auth B]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
CO	C [auth A], D [auth A], E [auth B], F [auth B]	COBALT (II) ION Co XLJKHNWPARRRJB-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
KCX	A, B	L-PEPTIDE LINKING	C7 H14 N2 O4		LYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:  0.249 (Depositor), 0.250 (DCC)
• R-Value Work:  0.222 (Depositor), 0.222 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.357	α = 90
b = 80.295	β = 99.35
c = 92.204	γ = 90

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-09-12
Deposition Author(s): An, J., Zhang, Z., Zhang, Y., Feng, Y., Wu, G.

Revision History

• Version 1.0: 2012-09-12
  Type: Initial release

• Version 1.1: 2025-03-26
  Changes: Data collection, Database references, Derived calculations, Structure summary
