3SH6 | pdb_00003sh6

Frog M-ferritin, D122R mutant, with magnesium

PDB DOI: https://doi.org/10.2210/pdb3SH6/pdb

Classification: OXIDOREDUCTASE
Organism(s): Aquarana catesbeiana
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2011-06-16 Released: 2012-02-29
Deposition Author(s): Tosha, T., Ng, H.L., Alber, T., Theil, E.C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free:
0.192 (Depositor), 0.194 (DCC)
R-Value Work:
0.166 (Depositor), 0.167 (DCC)
R-Value Observed:
0.167 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3SH6

This is version 1.1 of the entry. See complete history.

Literature

Frog M-ferritin, D122R mutant, with magnesium

Tosha, T., Ng, H.L., Alber, T., Theil, E.C.

To be published.

Macromolecule Content

Total Structure Weight: 20.94 kDa
Atom Count: 1,700
Modeled Residue Count: 174
Deposited Residue Count: 176
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ferritin, middle subunit	A	176	Aquarana catesbeiana	Mutation(s): 1 EC: 1.16.3.1
UniProt
Find proteins for P07798 (Aquarana catesbeiana) Explore P07798 Go to UniProtKB: P07798
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P07798
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A]	G [auth A], H [auth A], I [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain C [auth A] mmCIF format, chain B [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain C [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], J [auth A], K [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth A] Focus chain K [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free: 0.192 (Depositor), 0.194 (DCC)
R-Value Work: 0.166 (Depositor), 0.167 (DCC)
R-Value Observed: 0.167 (Depositor)

Space Group: F 4 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 183.374	α = 90
b = 183.374	β = 90
c = 183.374	γ = 90

Software Package:

Software Name	Purpose
Blu-Ice	data collection
PHASER	phasing
REFMAC	refinement
MOSFLM	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-02-29

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2012-02-29
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references, Derived calculations
