3Q9D | pdb_00003q9d

Crystal Structure of Cpn0803 from C. pneumoniae.

PDB DOI: https://doi.org/10.2210/pdb3Q9D/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Chlamydia pneumoniae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2011-01-07 Released: 2012-01-11
Deposition Author(s): Stone, C.B., Sugiman-Marangos, S.N., Junop, M.S., Mahony, J.B.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.208 (Depositor), 0.211 (DCC)
R-Value Work:
0.176 (Depositor), 0.177 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3Q9D

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Cpn0803 from C. pneumoniae.

Stone, C.B., Sugiman-Marangos, S.N., Junop, M.S., Mahony, J.B.

To be published.

Macromolecule Content

Total Structure Weight: 51.24 kDa
Atom Count: 3,206
Modeled Residue Count: 350
Deposited Residue Count: 440
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein CPn_0803/CP_1068/CPj0803/CpB0832	A, B	220	Chlamydia pneumoniae	Mutation(s): 0 Gene Names: CPn_0803, CP_1068, CPj0803, CpB0832
UniProt
Find proteins for Q9Z7A3 (Chlamydia pneumoniae) Explore Q9Z7A3 Go to UniProtKB: Q9Z7A3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9Z7A3
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.208 (Depositor), 0.211 (DCC)
R-Value Work: 0.176 (Depositor), 0.177 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.392	α = 90
b = 86.392	β = 90
c = 99.591	γ = 120

Software Package:

Software Name	Purpose
CBASS	data collection
SOLVE	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-01-11

Deposition Author(s):

Sugiman-Marangos, S.N.

Revision History (Full details and data files)

Version 1.0: 2012-01-11
Type: Initial release
Version 1.1: 2024-02-21
Changes: Data collection, Database references
