3P9Z

Crystal structure of uroporphyrinogen-III synthetase from Helicobacter pylori 26695

PDB DOI: https://doi.org/10.2210/pdb3P9Z/pdb

Classification: LIGASE
Organism(s): Helicobacter pylori
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-10-18 Released: 2010-11-03
Deposition Author(s): Nocek, B., Stein, A., Chhor, G., Fenske, R.J., Buck, K., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.241
R-Value Work: 0.202
R-Value Observed: 0.204

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of uroporphyrinogen-III synthetase from Helicobacter pylori 26695

Nocek, B., Stein, A., Chhor, G., Fenske, R.J., Buck, K., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 26.41 kDa
Atom Count: 1,815
Modelled Residue Count: 213
Deposited Residue Count: 229
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uroporphyrinogen III cosynthase (HemD)	A	229	Helicobacter pylori	Mutation(s): 0 Gene Names: HP_1224 EC: 4.2.1.75
UniProt
Find proteins for O25822 (Helicobacter pylori (strain ATCC 700392 / 26695)) Explore O25822 Go to UniProtKB: O25822
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O25822
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MLI Query on MLI Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MALONATE ION C₃ H₂ O₄ OFOBLEOULBTSOW-UHFFFAOYSA-L		Interactions Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.241
R-Value Work: 0.202
R-Value Observed: 0.204
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.407	α = 90
b = 57.676	β = 90
c = 74.624	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
Auto-Rickshaw	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2010-11-03

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-11-03
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
