3ORU | pdb_00003oru

Crystal structure of a DUF1989 family protein (TM1040_0329) from SILICIBACTER SP. TM1040 at 1.11 A resolution

PDB DOI: https://doi.org/10.2210/pdb3ORU/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Ruegeria sp. TM1040
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-09-07 Released: 2010-10-13
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.11 Å
R-Value Free:
0.146 (Depositor), 0.147 (DCC)
R-Value Work:
0.126 (Depositor), 0.127 (DCC)
R-Value Observed:
0.127 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3ORU

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a DUF1989 family protein (TM1040_0329) from SILICIBACTER SP. TM1040 at 1.11 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 26.43 kDa
Atom Count: 2,253
Modeled Residue Count: 231
Deposited Residue Count: 234
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DUF1989 family protein	A	234	Ruegeria sp. TM1040	Mutation(s): 0 Gene Names: TM1040_0329
UniProt
Find proteins for A0ACD6B8A6 (Ruegeria sp. (strain TM1040)) Explore A0ACD6B8A6 Go to UniProtKB: A0ACD6B8A6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0ACD6B8A6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.11 Å
R-Value Free: 0.146 (Depositor), 0.147 (DCC)
R-Value Work: 0.126 (Depositor), 0.127 (DCC)
R-Value Observed: 0.127 (Depositor)

Diffraction Data:

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.757	α = 90
b = 131.024	β = 90
c = 57.902	γ = 90

Software Package:

Software Name	Purpose
SHELX	phasing
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-10-13

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-10-13
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-07-20
Changes: Structure summary
Version 1.3: 2017-10-25
Changes: Author supporting evidence
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-06
Changes: Data collection, Structure summary
