3OET | pdb_00003oet

D-Erythronate-4-Phosphate Dehydrogenase complexed with NAD

PDB DOI: https://doi.org/10.2210/pdb3OET/pdb

Classification: OXIDOREDUCTASE
Organism(s): Salmonella enterica subsp. enterica serovar Typhimurium str. LT2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-08-13 Released: 2010-08-25
Deposition Author(s): Filippova, E.V., Wawrzak, Z., Onopriyenko, O., Savchenko, A., Edwards, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free:
0.253 (Depositor), 0.250 (DCC)
R-Value Work:
0.190 (Depositor), 0.190 (DCC)
R-Value Observed:
0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.5 of the entry. See complete history.

Literature

D-Erythronate-4-Phosphate Dehydrogenase complexed with NAD

Filippova, E.V., Wawrzak, Z., Onopriyenko, O., Savchenko, A., Edwards, A., Anderson, W.F.

To be published.

Macromolecule Content

Total Structure Weight: 340.16 kDa
Atom Count: 23,835
Modelled Residue Count: 2,987
Deposited Residue Count: 3,048
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Erythronate-4-phosphate dehydrogenase	A, B, C, D, E A, B, C, D, E, F, G, H	381	Salmonella enterica subsp. enterica serovar Typhimurium str. LT2	Mutation(s): 0 Gene Names: pdxB, STM2370 EC: 1.1.1.290
UniProt
Find proteins for P60802 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore P60802 Go to UniProtKB: P60802
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P60802
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD Query on NAD Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth B] SDF format, chain K [auth C] SDF format, chain L [auth D] SDF format, chain M [auth E] SDF format, chain N [auth F] SDF format, chain O [auth G] SDF format, chain P [auth H] MOL2 format, chain I [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth C] MOL2 format, chain L [auth D] MOL2 format, chain M [auth E] MOL2 format, chain N [auth F] MOL2 format, chain O [auth G] MOL2 format, chain P [auth H] mmCIF format, chain I [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth C] mmCIF format, chain L [auth D] mmCIF format, chain M [auth E] mmCIF format, chain N [auth F] mmCIF format, chain O [auth G] mmCIF format, chain P [auth H]	I [auth A] J [auth B] K [auth C] L [auth D] M [auth E] I [auth A], J [auth B], K [auth C], L [auth D], M [auth E], N [auth F], O [auth G], P [auth H]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth E] Focus chain N [auth F] Focus chain O [auth G] Focus chain P [auth H] Interactions & Density Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth E] Focus chain N [auth F] Focus chain O [auth G] Focus chain P [auth H]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D, E A, B, C, D, E, F, G, H	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free: 0.253 (Depositor), 0.250 (DCC)
R-Value Work: 0.190 (Depositor), 0.190 (DCC)
R-Value Observed: 0.193 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33oet

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.279	α = 90
b = 167.765	β = 93.88
c = 103.949	γ = 90

Software Package:

Software Name	Purpose
Blu-Ice	data collection
CCP4	model building
MrBUMP	phasing
PHENIX	model building
REFMAC	refinement
HKL-2000	data reduction
HKL-3000	data scaling
CCP4	phasing
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2010-08-25

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2010-08-25
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-08
Changes: Refinement description
Version 1.3: 2023-09-06
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.4: 2023-12-06
Changes: Data collection
Version 1.5: 2024-10-30
Changes: Structure summary
