3OCE | pdb_00003oce

Crystal structure of fumarate lyase:delta crystallin from Brucella melitensis bound to cobalt

PDB DOI: https://doi.org/10.2210/pdb3OCE/pdb

Classification: LYASE
Organism(s): Brucella abortus 2308
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-08-09 Released: 2010-08-18
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free:
0.245 (Depositor), 0.217 (DCC)
R-Value Work:
0.196 (Depositor)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of fumarate lyase:delta crystallin from Brucella melitensis bound to cobalt

Edwards, T.E., Arakaki, T.L., Sankaran, B.

To be published.

Macromolecule Content

Total Structure Weight: 204.8 kDa
Atom Count: 14,371
Modeled Residue Count: 1,842
Deposited Residue Count: 1,896
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fumarate lyase:Delta crystallin	A, B, C, D	474	Brucella abortus 2308	Mutation(s): 0 Gene Names: aspA, BAB1_1959 EC: 4.3.1.1
UniProt
Find proteins for Q2YLW1 (Brucella abortus (strain 2308)) Explore Q2YLW1 Go to UniProtKB: Q2YLW1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2YLW1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]
CO Query on CO Download:Ideal Coordinates CCD File SDF format, chain T [auth D] SDF format, chain S [auth D] SDF format, chain R [auth D] SDF format, chain P [auth C] SDF format, chain O [auth C] SDF format, chain N [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain T [auth D] MOL2 format, chain S [auth D] MOL2 format, chain R [auth D] MOL2 format, chain P [auth C] MOL2 format, chain O [auth C] MOL2 format, chain N [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain T [auth D] mmCIF format, chain S [auth D] mmCIF format, chain R [auth D] mmCIF format, chain P [auth C] mmCIF format, chain O [auth C] mmCIF format, chain N [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] J [auth B] K [auth B] E [auth A], F [auth A], G [auth A], J [auth B], K [auth B], L [auth B], N [auth C], O [auth C], P [auth C], R [auth D], S [auth D], T [auth D]	COBALT (II) ION Co XLJKHNWPARRRJB-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain U [auth D] SDF format, chain Q [auth C] SDF format, chain M [auth B] SDF format, chain H [auth A] MOL2 format, chain U [auth D] MOL2 format, chain Q [auth C] MOL2 format, chain M [auth B] MOL2 format, chain H [auth A] mmCIF format, chain U [auth D] mmCIF format, chain Q [auth C] mmCIF format, chain M [auth B] mmCIF format, chain H [auth A]	H [auth A], M [auth B], Q [auth C], U [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain M [auth B] Focus chain Q [auth C] Focus chain U [auth D] Interactions & Density Focus chain H [auth A] Focus chain M [auth B] Focus chain Q [auth C] Focus chain U [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free: 0.245 (Depositor), 0.217 (DCC)
R-Value Work: 0.196 (Depositor)
R-Value Observed: 0.198 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.33	α = 90
b = 113.55	β = 90
c = 236.86	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-08-18

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2010-08-18
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2019-11-20
Changes: Database references, Derived calculations
Version 1.3: 2023-09-06
Changes: Data collection, Database references, Derived calculations, Refinement description
