3O60 | pdb_00003o60

The Crystal Structure of Lin0861 from Listeria innocua to 2.8A

• PDB DOI: https://doi.org/10.2210/pdb3O60/pdb

• Classification: Structural Genomics, Unknown function
• Organism(s): Listeria innocua
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2010-07-28 Released: 2010-09-29
• Deposition Author(s): Stein, A.J., Rakowski, E., Feldmann, B., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:
  0.246 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.220 (Depositor)
• R-Value Observed:
  0.217 (Depositor)

Literature

The Crystal Structure of Lin0861 from Listeria innocua to 2.8A

Stein, A.J., Rakowski, E., Feldmann, B., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 44.84 kDa
• Atom Count: 2,917
• Modeled Residue Count: 364
• Deposited Residue Count: 370
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lin0861 protein	A, B	185	Listeria innocua	Mutation(s): 0
UniProt
Find proteins for Q92DF2 (Listeria innocua serovar 6a (strain ATCC BAA-680 / CLIP 11262)) Explore Q92DF2  Go to UniProtKB:  Q92DF2

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth A], E [auth B], F [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:  0.246 (Depositor), 0.240 (DCC)
• R-Value Work:  0.220 (Depositor)
• R-Value Observed: 0.217 (Depositor)

Space Group: P 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.457	α = 90
b = 95.457	β = 90
c = 96.84	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	phasing
SHELX	phasing
MLPHARE	phasing
DM	phasing
RESOLVE	phasing
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-09-29
Deposition Author(s): Stein, A.J., Rakowski, E., Feldmann, B., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-09-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
