3O5V | pdb_00003o5v

The Crystal Structure of the Creatinase/Prolidase N-terminal domain of an X-PRO dipeptidase from Streptococcus pyogenes to 1.85A

• PDB DOI: https://doi.org/10.2210/pdb3O5V/pdb

• Classification: HYDROLASE
• Organism(s): Streptococcus pyogenes M1 GAS
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2010-07-28 Released: 2010-08-11
• Deposition Author(s): Stein, A.J., Wu, R., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:
  0.224 (Depositor), 0.226 (DCC)
• R-Value Work:
  0.192 (Depositor), 0.192 (DCC)
• R-Value Observed:
  0.194 (Depositor)

Literature

The Crystal Structure of the Creatinase/Prolidase N-terminal domain of an X-PRO dipeptidase from Streptococcus pyogenes to 1.85A

Stein, A.J., Wu, R., Clancy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 assigned by authors.

Macromolecule Content

• Total Structure Weight: 30.31 kDa
• Atom Count: 2,241
• Modeled Residue Count: 254
• Deposited Residue Count: 264
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
X-PRO dipeptidase	A, B	132	Streptococcus pyogenes M1 GAS	Mutation(s): 0  Gene Names: M5005_Spy0423, pepQ, SPy_0513 EC: 3.4.13.9
UniProt
Find proteins for Q9A119 (Streptococcus pyogenes serotype M1) Explore Q9A119  Go to UniProtKB:  Q9A119

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	C [auth A], D [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:  0.224 (Depositor), 0.226 (DCC)
• R-Value Work:  0.192 (Depositor), 0.192 (DCC)
• R-Value Observed: 0.194 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.439	α = 90
b = 79.439	β = 90
c = 88.823	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELX	phasing
MLPHARE	phasing
DM	phasing
ARP/wARP	model building
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-08-11
Deposition Author(s): Stein, A.J., Wu, R., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-08-11
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
