3NZG | pdb_00003nzg

Crystal structure of a putative racemase with Mg ion

PDB DOI: https://doi.org/10.2210/pdb3NZG/pdb

Classification: ISOMERASE
Organism(s): Pseudovibrio sp. JE062
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2010-07-16 Released: 2010-08-11
Deposition Author(s): Eswaramoorthy, S., Raparia, E., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.244 (Depositor), 0.236 (DCC)
R-Value Work:
0.221 (Depositor), 0.215 (DCC)
R-Value Observed:
0.221 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.6 of the entry. See complete history.

Literature

Crystal structure of a putative racemase with Mg ion

Eswaramoorthy, S., Raparia, E., Burley, S.K., Swaminathan, S.

To be published.

Macromolecule Content

Total Structure Weight: 178.42 kDa
Atom Count: 12,214
Modeled Residue Count: 1,511
Deposited Residue Count: 1,576
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative racemase	A, B, C, D	394	Pseudovibrio sp. JE062	Mutation(s): 0 Gene Names: PJE062_745

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain O [auth D] SDF format, chain M [auth C] SDF format, chain L [auth C] SDF format, chain H [auth B] SDF format, chain E [auth A] MOL2 format, chain O [auth D] MOL2 format, chain M [auth C] MOL2 format, chain L [auth C] MOL2 format, chain H [auth B] MOL2 format, chain E [auth A] mmCIF format, chain O [auth D] mmCIF format, chain M [auth C] mmCIF format, chain L [auth C] mmCIF format, chain H [auth B] mmCIF format, chain E [auth A]	E [auth A], H [auth B], L [auth C], M [auth C], O [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain O [auth D]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain Q [auth D] SDF format, chain P [auth D] SDF format, chain N [auth C] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain Q [auth D] MOL2 format, chain P [auth D] MOL2 format, chain N [auth C] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain Q [auth D] mmCIF format, chain P [auth D] mmCIF format, chain N [auth C] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A] G [auth A] I [auth B] J [auth B] K [auth B] F [auth A], G [auth A], I [auth B], J [auth B], K [auth B], N [auth C], P [auth D], Q [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.244 (Depositor), 0.236 (DCC)
R-Value Work: 0.221 (Depositor), 0.215 (DCC)
R-Value Observed: 0.221 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 132.144	α = 90
b = 165.408	β = 90
c = 165.666	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
MOLREP	phasing
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-08-11

Deposition Author(s):

New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History (Full details and data files)

Version 1.0: 2010-08-11
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-11-16
Changes: Atomic model
Version 1.3: 2021-02-10
Changes: Database references, Derived calculations, Structure summary
Version 1.4: 2023-09-06
Changes: Data collection, Database references, Refinement description
Version 1.5: 2023-11-22
Changes: Data collection
Version 1.6: 2024-11-20
Changes: Structure summary
