3MEL | pdb_00003mel

Crystal Structure of Thiamin pyrophosphokinase family protein from Enterococcus faecalis, Northeast Structural Genomics Consortium Target EfR150

PDB DOI: https://doi.org/10.2210/pdb3MEL/pdb

Classification: structural genomics, unknown function
Organism(s): Enterococcus faecalis
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2010-03-31 Released: 2010-05-05
Deposition Author(s): Kuzin, A., Abasidze, M., Seetharaman, J., Mao, M., Xiao, R., Ciccosanti, C., Foote, E.L., Maglaqui, M., Zhao, L., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Snell, E.H., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.79 Å
R-Value Free:
0.249 (Depositor), 0.249 (DCC)
R-Value Work:
0.168 (Depositor), 0.167 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.0 of the entry. See complete history.

Literature

Northeast Structural Genomics Consortium Target EfR150

Kuzin, A., Abasidze, M., Seetharaman, J., Mao, M., Xiao, R., Ciccosanti, C., Foote, E.L., Maglaqui, M., Zhao, L., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L.

To be published.

Macromolecule Content

Total Structure Weight: 98.34 kDa
Atom Count: 6,954
Modeled Residue Count: 852
Deposited Residue Count: 852
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Thiamine diphosphokinase	A, B, C, D	213	Enterococcus faecalis	Mutation(s): 0 Gene Names: thiN, DAI13_15455, NCTC13379_00805, P0083_14635, P0D81_02330, P0E79_12185 EC: 2.7.6.2
UniProt
Find proteins for Q82ZE3 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q82ZE3 Go to UniProtKB: Q82ZE3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q82ZE3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TPP (Subject of Investigation/LOI) Query on TPP Download Ideal Coordinates CCD File SDF format, chain O [auth D] SDF format, chain E [auth A] MOL2 format, chain O [auth D] MOL2 format, chain E [auth A] mmCIF format, chain O [auth D] mmCIF format, chain E [auth A]	E [auth A], O [auth D]	THIAMINE DIPHOSPHATE C₁₂ H₁₉ N₄ O₇ P₂ S AYEKOFBPNLCAJY-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain O [auth D]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain P [auth D] SDF format, chain L [auth C] SDF format, chain I [auth B] SDF format, chain F [auth A] MOL2 format, chain P [auth D] MOL2 format, chain L [auth C] MOL2 format, chain I [auth B] MOL2 format, chain F [auth A] mmCIF format, chain P [auth D] mmCIF format, chain L [auth C] mmCIF format, chain I [auth B] mmCIF format, chain F [auth A]	F [auth A], I [auth B], L [auth C], P [auth D]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain P [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain P [auth D]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain Q [auth D] SDF format, chain M [auth C] SDF format, chain J [auth B] SDF format, chain G [auth A] MOL2 format, chain Q [auth D] MOL2 format, chain M [auth C] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] mmCIF format, chain Q [auth D] mmCIF format, chain M [auth C] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A]	G [auth A], J [auth B], M [auth C], Q [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain Q [auth D] Interactions & Density Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain Q [auth D]
FE Query on FE Download Ideal Coordinates CCD File SDF format, chain R [auth D] SDF format, chain N [auth C] SDF format, chain K [auth B] SDF format, chain H [auth A] MOL2 format, chain R [auth D] MOL2 format, chain N [auth C] MOL2 format, chain K [auth B] MOL2 format, chain H [auth A] mmCIF format, chain R [auth D] mmCIF format, chain N [auth C] mmCIF format, chain K [auth B] mmCIF format, chain H [auth A]	H [auth A], K [auth B], N [auth C], R [auth D]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain R [auth D] Interactions & Density Focus chain H [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain R [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.79 Å
R-Value Free: 0.249 (Depositor), 0.249 (DCC)
R-Value Work: 0.168 (Depositor), 0.167 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.286	α = 90
b = 102.112	β = 98.126
c = 94.277	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
HKL-2000	data reduction
SCALEPACK	data scaling
SHELXD	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2010-05-05

Deposition Author(s):

Northeast Structural Genomics Consortium (NESG)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2010-05-05
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.3: 2024-04-03
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.4: 2024-10-30
Changes: Structure summary
Version 2.0: 2026-04-08
Type: Coordinate replacement
Reason: Ligand identity
Changes: Advisory, Atomic model, Author supporting evidence, Data collection, Database references, Derived calculations, Non-polymer description, Other, Polymer sequence, Refinement description, Source and taxonomy, Structure summary
