3M4Y

Structural characterization of the subunit A mutant P235A of the A-ATP synthase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.38 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.199
  • R-Value Observed: 0.202

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

The critical roles of residues P235 and F236 of subunit A of the motor protein A-ATP synthase in P-loop formation and nucleotide binding.

Kumar, A.Manimekalai, M.S.Balakrishna, A.M.Priya, R.Biukovic, G.Jeyakanthan, J.Gruber, G.

(2010) J Mol Biol 401: 892-905

  • DOI: https://doi.org/10.1016/j.jmb.2010.06.070
  • Primary Citation of Related Structures:
    3M4Y, 3MFY

  • PubMed Abstract:

    The mutants P235A and F236A have been generated and their crystal structure was determined to resolutions of 2.38 and 2.35 A, respectively, in order to understand the residues involved in the formation of the novel arched P-loop of subunit A of the A-ATP synthase from Pyrococcus horikoshii OT3. Both the structures show unique, altered conformations for the P-loop. Comparison with the previously solved wild type and P-loop mutant S238A structures of subunit A showed that the P-loop conformation for these two novel mutants occupy intermediate positions, with the wild type fully arched and the well-relaxed S238A mutant structures taking the extreme positions. Even though the deviation is similar for both mutants, the curvature of the P-loop faces the opposite direction. Deviations in the GER-loop, lying above the P-loop, are similar for both mutants, but in F236A, it moves towards the P-loop by around 2 A. The curvature of the loop region V392-V410, located directly behind the P-loop, moves close by 3.6 A towards the P-loop in the F236A structure and away by 2.5 A in the P235A structure. Two major deviations were observed in the P235A mutant, which are not identified in any of the subunit A structures analyzed so far, one being a wide movement of the N-terminal loop region (R90-P110) making a rotation of 80 degrees and the other being rigid-body rotation of the C-terminal helices from Q520-A588 by around 4 degrees upwards. Taken together, the data presented demonstrate the concerted effects of the critical residues P235A, F236, and S238 in the unique P-loop conformation of the A-ATP synthases.


  • Organizational Affiliation

    School of Biological Sciences, Nanyang Technological University, 60 Nanyang Drive, Singapore 637551, Republic of Singapore.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
V-type ATP synthase alpha chain588Pyrococcus horikoshii OT3Mutation(s): 1
Gene Names: atpAPH1975
EC: 3.6.3.14 (PDB Primary Data), 7.1.2.2 (UniProt)
UniProt
Find proteins for O57728 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3))
Explore O57728
Go to UniProtKB:  O57728
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO57728
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TRS
Query on TRS

Download Ideal Coordinates CCD File
E [auth A]2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
MPD
Query on MPD

Download Ideal Coordinates CCD File
B [auth A],
C [auth A],
D [auth A],
H [auth A]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
ACY
Query on ACY

Download Ideal Coordinates CCD File
F [auth A],
G [auth A]
ACETIC ACID
C2 H4 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.38 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.199
  • R-Value Observed: 0.202
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 127.564α = 90
b = 127.564β = 90
c = 105.403γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
ADSCdata collection

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-01-26
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-08-23
    Changes: Refinement description, Source and taxonomy
  • Version 1.3: 2017-11-08
    Changes: Refinement description
  • Version 1.4: 2021-11-10
    Changes: Database references, Derived calculations
  • Version 1.5: 2023-11-01
    Changes: Data collection, Refinement description
