3M0J | pdb_00003m0j

Structure of oxaloacetate acetylhydrolase in complex with the inhibitor 3,3-difluorooxalacetate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free:
    0.201 (Depositor), 0.205 (DCC)
  • R-Value Work:
    0.175 (Depositor), 0.177 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3M0J

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structure of oxalacetate acetylhydrolase, a virulence factor of the chestnut blight fungus.

Chen, C.Sun, Q.Narayanan, B.Nuss, D.L.Herzberg, O.

(2010) J Biological Chem 285: 26685-26696

  • DOI: https://doi.org/10.1074/jbc.M110.117804
  • Primary Citation Related Structures:
    3LYE, 3M0J, 3M0K

  • PubMed Abstract:

    Oxalacetate acetylhydrolase (OAH), a member of the phosphoenolpyruvate mutase/isocitrate lyase superfamily, catalyzes the hydrolysis of oxalacetate to oxalic acid and acetate. This study shows that knock-out of the oah gene in Cryphonectria parasitica, the chestnut blight fungus, reduces the ability of the fungus to form cankers on chestnut trees, suggesting that OAH plays a key role in virulence. OAH was produced in Escherichia coli and purified, and its catalytic rates were determined. Oxalacetate is the main OAH substrate, but the enzyme also acts as a lyase of (2R,3S)-dimethyl malate with approximately 1000-fold lower efficacy. The crystal structure of OAH was determined alone, in complex with a mechanism-based inhibitor, 3,3-difluorooxalacetate (DFOA), and in complex with the reaction product, oxalate, to a resolution limit of 1.30, 1.55, and 1.65 A, respectively. OAH assembles into a dimer of dimers with each subunit exhibiting an (alpha/beta)(8) barrel fold and each pair swapping the 8th alpha-helix. An active site "gating loop" exhibits conformational disorder in the ligand-free structure. To obtain the structures of the OAH.ligand complexes, the ligand-free OAH crystals were soaked briefly with DFOA or oxalacetate. DFOA binding leads to ordering of the gating loop in a conformation that sequesters the ligand from the solvent. DFOA binds in a gem-diol form analogous to the oxalacetate intermediate/transition state. Oxalate binds in a planar conformation, but the gating loop is largely disordered. Comparison between the OAH structure and that of the closely related enzyme, 2,3-dimethylmalate lyase, suggests potential determinants of substrate preference.


  • Organizational Affiliation
    • W. M. Keck Laboratory for Structural Biology, Center for Advanced Research in Biotechnology, University of Maryland Biotechnology Institute, Rockville, Maryland 20850, USA.

Macromolecule Content

  • Total Structure Weight: 33.38 kDa
  • Atom Count: 2,605
  • Modeled Residue Count: 297
  • Deposited Residue Count: 307
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Oxaloacetate acetyl hydrolase307Cryphonectria parasiticaMutation(s): 0
Gene Names: OAH
EC: 3.7.1.1

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free:  0.201 (Depositor), 0.205 (DCC)
  • R-Value Work:  0.175 (Depositor), 0.177 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: P 42 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.144α = 90
b = 82.144β = 90
c = 72.66γ = 90
Software Package:
Software NamePurpose
PHASERphasing
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-06-16
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2023-09-06
    Changes: Data collection, Database references, Derived calculations, Refinement description
