3KWS | pdb_00003kws

Crystal structure of Putative sugar isomerase (YP_001305149.1) from Parabacteroides distasonis ATCC 8503 at 1.68 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3KWS/pdb

• Classification: ISOMERASE
• Organism(s): Parabacteroides distasonis ATCC 8503
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-12-01 Released: 2009-12-22
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.68 Å
• R-Value Free:
  0.182 (Depositor), 0.193 (DCC)
• R-Value Work:
  0.150 (Depositor), 0.162 (DCC)
• R-Value Observed:
  0.152 (Depositor)

Literature

Crystal structure of Putative sugar isomerase (YP_001305149.1) from Parabacteroides distasonis ATCC 8503 at 1.68 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 63.76 kDa
• Atom Count: 5,113
• Modeled Residue Count: 530
• Deposited Residue Count: 574
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative sugar isomerase	A, B	287	Parabacteroides distasonis ATCC 8503	Mutation(s): 0  Gene Names: BDI_3843
UniProt
Find proteins for A6LIL3 (Parabacteroides distasonis (strain ATCC 8503 / DSM 20701 / CIP 104284 / JCM 5825 / NCTC 11152)) Explore A6LIL3  Go to UniProtKB:  A6LIL3

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	D [auth A], E [auth A], G [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
MG	C [auth A], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.68 Å
• R-Value Free:  0.182 (Depositor), 0.193 (DCC)
• R-Value Work:  0.150 (Depositor), 0.162 (DCC)
• R-Value Observed: 0.152 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33KWS

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.573	α = 90
b = 107.2	β = 90
c = 113.146	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-12-22
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-12-22
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-17
  Changes: Advisory, Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-27
  Changes: Data collection, Refinement description, Structure summary
