3KWK | pdb_00003kwk

Crystal structure of Putative NADH dehydrogenase/NAD(P)H nitroreductase (NP_809094.1) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.54 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3KWK/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Bacteroides thetaiotaomicron VPI-5482
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-12-01 Released: 2009-12-15
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.54 Å
• R-Value Free:
  0.176 (Depositor), 0.192 (DCC)
• R-Value Work:
  0.146 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.147 (Depositor)

Literature

Crystal structure of Putative NADH dehydrogenase/NAD(P)H nitroreductase (NP_809094.1) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.54 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 20.39 kDa
• Atom Count: 1,742
• Modeled Residue Count: 168
• Deposited Residue Count: 175
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative NADH dehydrogenase/NAD(P)H nitroreductase	A	175	Bacteroides thetaiotaomicron VPI-5482	Mutation(s): 0  Gene Names: BT_0181
UniProt
Find proteins for Q8ABC9 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q8ABC9  Go to UniProtKB:  Q8ABC9

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FMN	B [auth A]	FLAVIN MONONUCLEOTIDE C17 H21 N4 O9 P FVTCRASFADXXNN-SCRDCRAPSA-N
CL	D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
UNL	C [auth A]	Unknown ligand VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.54 Å
• R-Value Free:  0.176 (Depositor), 0.192 (DCC)
• R-Value Work:  0.146 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.147 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33KWK

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.215	α = 90
b = 42.215	β = 90
c = 186.713	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-12-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-12-15
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-17
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-30
  Changes: Data collection, Structure summary
