3KTD | pdb_00003ktd

CRYSTAL STRUCTURE OF A PUTATIVE PREPHENATE DEHYDROGENASE (CGL0226) FROM CORYNEBACTERIUM GLUTAMICUM ATCC 13032 AT 2.60 A RESOLUTION

PDB DOI: https://doi.org/10.2210/pdb3KTD/pdb

Classification: OXIDOREDUCTASE
Organism(s): Corynebacterium glutamicum ATCC 13032
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-11-24 Released: 2010-02-02
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.254 (Depositor), 0.260 (DCC)
R-Value Work:
0.213 (Depositor), 0.222 (DCC)
R-Value Observed:
0.215 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3KTD

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of Prephenate dehydrogenase (NP_599479.1) from CORYNEBACTERIUM GLUTAMICUM ATCC 13032 KITASATO at 2.60 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 147.05 kDa
Atom Count: 9,588
Modeled Residue Count: 1,281
Deposited Residue Count: 1,364
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Prephenate dehydrogenase	A, B, C, D	341	Corynebacterium glutamicum ATCC 13032	Mutation(s): 0 Gene Names: Cgl0226
UniProt
Find proteins for Q8NTS6 (Corynebacterium glutamicum (strain ATCC 13032 / DSM 20300 / JCM 1318 / BCRC 11384 / CCUG 27702 / LMG 3730 / NBRC 12168 / NCIMB 10025 / NRRL B-2784 / 534)) Explore Q8NTS6 Go to UniProtKB: Q8NTS6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8NTS6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.254 (Depositor), 0.260 (DCC)
R-Value Work: 0.213 (Depositor), 0.222 (DCC)
R-Value Observed: 0.215 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.322	α = 90
b = 107.23	β = 90
c = 146.915	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-02-02

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-02-02
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-27
Changes: Data collection, Refinement description, Structure summary
