3KGP

Crystal Structures of Urokinase-type Plasminogen Activator in Complex with 4-(Aminomethyl) Benzoic Acid and 4-(Aminomethyl-phenyl)-methanol

PDB DOI: https://doi.org/10.2210/pdb3KGP/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Komagataella pastoris
Mutation(s): Yes

Deposited: 2009-10-29 Released: 2009-12-01
Deposition Author(s): Jiang, L.-G., Zhao, G.-X., Bian, X.-B., Yuan, C., Huang, Z.-X., Huang, M.-D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.274
R-Value Work: 0.199
R-Value Observed: 0.199

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.5 of the entry. See complete history.

Literature

Crystal Structures of Urokinase-type Plasminogen Activator in Complex with 4-(Aminomethyl) Benzoic Acid and 4-(Aminomethyl-phenyl)-methanol

Jiang, L.-G., Zhao, G.-X., Bian, X.-B., Yuan, C., Huang, Z.-X., Huang, M.-D.

(2009) Chin J Struct Chem 28: 253-259

Macromolecule Content

Total Structure Weight: 28.69 kDa
Atom Count: 2,148
Modelled Residue Count: 239
Deposited Residue Count: 253
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Urokinase-type plasminogen activator	A	253	Homo sapiens	Mutation(s): 2 Gene Names: PLAU EC: 3.4.21.73
UniProt & NIH Common Fund Data Resources
Find proteins for P00749 (Homo sapiens) Explore P00749 Go to UniProtKB: P00749
PHAROS: P00749 GTEx: ENSG00000122861
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P00749
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
4AZ Query on 4AZ Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	4-(aminomethyl)benzoic acid C₈ H₉ N O₂ QCTBMLYLENLHLA-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Binding Affinity Annotations
ID	Source	Binding Affinity
4AZ	PDBBind: 3KGP	Ki: 2.68e+6 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.274
R-Value Work: 0.199
R-Value Observed: 0.199
Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 120.834	α = 90
b = 120.834	β = 90
c = 42.488	γ = 120

Software Package:

Software Name	Purpose
CNS	refinement
PROTEUM PLUS	data collection
PROTEUM PLUS	data reduction
SCALEPACK	data scaling
CNS	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2009-12-01

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2009-12-01
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2019-12-25
Changes: Data collection
Version 1.3: 2021-11-10
Changes: Database references, Derived calculations
Version 1.4: 2023-11-01
Changes: Data collection, Refinement description
Version 1.5: 2024-10-30
Changes: Structure summary
