3K3U | pdb_00003k3u

The V59W mutation blocks the distal pocket of the hemoglobin dehaloperoxidase from Amphitrite ornata

PDB DOI: https://doi.org/10.2210/pdb3K3U/pdb

Classification: OXIDOREDUCTASE
Organism(s): Amphitrite ornata
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2009-10-05 Released: 2010-11-03
Deposition Author(s): de Serrano, V., Davis, M.F., Franzen, S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.63 Å
R-Value Free:
0.201 (Depositor), 0.199 (DCC)
R-Value Work:
0.168 (Depositor), 0.166 (DCC)
R-Value Observed:
0.170 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3K3U

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

The V59W mutation blocks the distal pocket of the hemoglobin dehaloperoxidase from Amphitrite ornata

Davis, M.F., de Serrano, V., Gracz, H., Vendreix, F.A.P., Somasundram, A., Negrerie, M., Franzen, S.

To be published.

Macromolecule Content

Total Structure Weight: 33.08 kDa
Atom Count: 3,504
Modeled Residue Count: 274
Deposited Residue Count: 274
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dehaloperoxidase A	A, B	137	Amphitrite ornata	Mutation(s): 1 Gene Names: dhpA
UniProt
Find proteins for Q9NAV8 (Amphitrite ornata) Explore Q9NAV8 Go to UniProtKB: Q9NAV8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9NAV8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM Query on HEM Download:Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain C [auth A] MOL2 format, chain H [auth B] MOL2 format, chain C [auth A] mmCIF format, chain H [auth B] mmCIF format, chain C [auth A]	C [auth A], H [auth B]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain C [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] I [auth B] D [auth A], E [auth A], F [auth A], G [auth A], I [auth B], J [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.63 Å
R-Value Free: 0.201 (Depositor), 0.199 (DCC)
R-Value Work: 0.168 (Depositor), 0.166 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.766	α = 90
b = 67.321	β = 90
c = 69.462	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHASER	phasing
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-11-03

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-11-03
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2021-10-13
Changes: Database references, Derived calculations
Version 1.3: 2024-02-21
Changes: Data collection
