3IZ4 | pdb_00003iz4

Modified E. coli tmRNA in the resume state with the tRNA-like domain in the ribosomal P site interacting with the SmpB


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 13.6 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 3IZ4

This is version 1.3 of the entry. See complete history

Literature

Visualizing the transfer-messenger RNA as the ribosome resumes translation.

Fu, J.Hashem, Y.Wower, I.Lei, J.Liao, H.Y.Zwieb, C.Wower, J.Frank, J.

(2010) EMBO J 29: 3819-3825

  • DOI: https://doi.org/10.1038/emboj.2010.255
  • Primary Citation Related Structures:
    3IZ4

  • PubMed Abstract:

    Bacterial ribosomes stalled by truncated mRNAs are rescued by transfer-messenger RNA (tmRNA), a dual-function molecule that contains a tRNA-like domain (TLD) and an internal open reading frame (ORF). Occupying the empty A site with its TLD, the tmRNA enters the ribosome with the help of elongation factor Tu and a protein factor called small protein B (SmpB), and switches the translation to its own ORF. In this study, using cryo-electron microscopy, we obtained the first structure of an in vivo-formed complex containing ribosome and the tmRNA at the point where the TLD is accommodated into the ribosomal P site. We show that tmRNA maintains a stable 'arc and fork' structure on the ribosome when its TLD moves to the ribosomal P site and translation resumes on its ORF. Based on the density map, we built an atomic model, which suggests that SmpB interacts with the five nucleotides immediately upstream of the resume codon, thereby determining the correct selection of the reading frame on the ORF of tmRNA.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY, USA.

Macromolecule Content

  • Total Structure Weight: 135.74 kDa
  • Atom Count: 9,018
  • Modeled Residue Count: 495
  • Deposited Residue Count: 499
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
SsrA-binding protein122Escherichia coliMutation(s): 0
UniProt
Find proteins for Q8RR57 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RR57
Go to UniProtKB:  Q8RR57
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RR57
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 1
MoleculeChains LengthOrganismImage
Modified E. coli transfer-messenger RNA377Escherichia coli
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 13.6 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONSPIDER

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-10-20
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2018-07-18
    Changes: Data collection
  • Version 1.3: 2024-02-21
    Changes: Data collection, Database references
