3IV7

Crystal structure of Iron-containing alcohol dehydrogenase (NP_602249.1) from Corynebacterium glutamicum ATCC 13032 KITASATO at 2.07 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3IV7/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Corynebacterium glutamicum
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-08-31 Released: 2009-09-22
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.07 Å
• R-Value Free:
  0.221 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.171 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Literature

Crystal structure of Iron-containing alcohol dehydrogenase (NP_602249.1) from Corynebacterium glutamicum ATCC 13032 KITASATO at 2.07 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 77.83 kDa
• Atom Count: 5,681
• Modelled Residue Count: 712
• Deposited Residue Count: 728
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alcohol dehydrogenase IV	A, B	364	Corynebacterium glutamicum	Mutation(s): 0  Gene Names: cg3386, Cgl3057, NP_602249.1, tcbF EC: 1.3.1.32
UniProt
Find proteins for Q8NL91 (Corynebacterium glutamicum (strain ATCC 13032 / DSM 20300 / JCM 1318 / BCRC 11384 / CCUG 27702 / LMG 3730 / NBRC 12168 / NCIMB 10025 / NRRL B-2784 / 534)) Explore Q8NL91  Go to UniProtKB:  Q8NL91

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	F [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO	C [auth A], D [auth A], E [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.07 Å
• R-Value Free:  0.221 (Depositor), 0.240 (DCC)
• R-Value Work:  0.171 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.173 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33IV7

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.728	α = 90
b = 79.003	β = 90
c = 160.185	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-09-22
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-09-22
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-27
  Changes: Data collection, Refinement description, Structure summary
