3H7M | pdb_00003h7m

Crystal Structure of a Histidine Kinase Sensor Domain with Similarity to Periplasmic Binding Proteins

PDB DOI: https://doi.org/10.2210/pdb3H7M/pdb

Classification: TRANSFERASE
Organism(s): Geobacter sulfurreducens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-04-27 Released: 2009-06-30
Deposition Author(s): Cheung, J., Le-Khac, M., Hendrickson, W.A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.285 (Depositor), 0.226 (DCC)
R-Value Work:
0.228 (Depositor), 0.236 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 3H7M

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a histidine kinase sensor domain with similarity to periplasmic binding proteins.

Cheung, J., Le-Khac, M., Hendrickson, W.A.

(2009) Proteins 77: 235-241

PubMed: 19544572 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1002/prot.22485
Primary Citation Related Structures:
3H7M

Organizational Affiliation

Department of Biochemistry and Molecular Biophysics, Columbia University, New York, New York 10032, USA.

Macromolecule Content

Total Structure Weight: 25.98 kDa
Atom Count: 1,951
Modeled Residue Count: 228
Deposited Residue Count: 234
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sensor protein	A	234	Geobacter sulfurreducens	Mutation(s): 0 Gene Names: GSU2755 EC: 2.7.13.3
UniProt
Find proteins for Q749I7 (Geobacter sulfurreducens (strain ATCC 51573 / DSM 12127 / PCA)) Explore Q749I7 Go to UniProtKB: Q749I7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q749I7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.285 (Depositor), 0.226 (DCC)
R-Value Work: 0.228 (Depositor), 0.236 (DCC)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 122.92	α = 90
b = 122.92	β = 90
c = 81.692	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
SHARP	phasing
DM	phasing
CNS	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-06-30

Deposition Author(s):

Hendrickson, W.A.

Revision History (Full details and data files)

Version 1.0: 2009-06-30
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2024-02-21
Changes: Data collection, Database references, Derived calculations
