3H36 | pdb_00003h36

Structure of an uncharacterized domain in polyribonucleotide nucleotidyltransferase from Streptococcus mutans UA159

PDB DOI: https://doi.org/10.2210/pdb3H36/pdb

Classification: TRANSFERASE
Organism(s): Streptococcus mutans
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-04-15 Released: 2009-05-12
Deposition Author(s): Cuff, M.E., Hatzos, C., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.236 (Depositor), 0.239 (DCC)
R-Value Work:
0.199 (Depositor), 0.209 (DCC)
R-Value Observed:
0.201 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3H36

This is version 1.3 of the entry. See complete history.

Literature

Structure of an uncharacterized domain in polyribonucleotide nucleotidyltransferase from Streptococcus mutans UA159

Cuff, M.E., Hatzos, C., Jedrzejczak, R., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 10.97 kDa
Atom Count: 783
Modeled Residue Count: 78
Deposited Residue Count: 93
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Polyribonucleotide nucleotidyltransferase	A	93	Streptococcus mutans	Mutation(s): 0 Gene Names: pnp, pnpA, SMU_155 EC: 2.7.7.8
UniProt
Find proteins for Q8DWB2 (Streptococcus mutans serotype c (strain ATCC 700610 / UA159)) Explore Q8DWB2 Go to UniProtKB: Q8DWB2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DWB2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.236 (Depositor), 0.239 (DCC)
R-Value Work: 0.199 (Depositor), 0.209 (DCC)
R-Value Observed: 0.201 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.312	α = 90
b = 59.312	β = 90
c = 93.09	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MLPHARE	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
CCP4	phasing
O	model building
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-05-12

Deposition Author(s):

Jedrzejczak, R.

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2009-05-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
