3H1R | pdb_00003h1r

Order-disorder structure of fluorescent protein FP480

• PDB DOI: https://doi.org/10.2210/pdb3H1R/pdb

• Classification: FLUORESCENT PROTEIN
• Organism(s): Entacmaea quadricolor
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-04-13 Released: 2009-09-08
• Deposition Author(s): Pletnev, S., Morozova, K.S., Verkhusha, V.V., Dauter, Z.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.41 Å
• R-Value Free:
  0.321 (Depositor), 0.332 (DCC)
• R-Value Work:
  0.228 (Depositor), 0.221 (DCC)
• R-Value Observed:
  0.236 (Depositor)

Literature

Rotational order-disorder structure of fluorescent protein FP480

Pletnev, S., Morozova, K.S., Verkhusha, V.V., Dauter, Z.

(2009) Acta Crystallogr D Biol Crystallogr 65: 906-912

• PubMed: 19690368
• DOI: https://doi.org/10.1107/S0907444909020927
• Primary Citation Related Structures:
  3H1O, 3H1R


• PubMed Abstract:


  In the last decade, advances in instrumentation and software development have made crystallography a powerful tool in structural biology. Using this method, structural information can now be acquired from pathological crystals that would have been abandoned in earlier times. In this paper, the order-disorder (OD) structure of fluorescent protein FP480 is discussed. The structure is composed of tetramers with 222 symmetry incorporated into the lattice in two different ways, namely rotated 90 degrees with respect to each other around the crystal c axis, with tetramer axes coincident with crystallographic twofold axes. The random distribution of alternatively oriented tetramers in the crystal creates a rotational OD structure with statistically averaged I422 symmetry, although the presence of very weak and diffuse additional reflections suggests that the randomness is only approximate.

---

Organizational Affiliation:
• SAIC-Frederick Inc., Basic Research Program, Argonne National Laboratory, Argonne, IL 60439, USA. [e-mail]

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 26.34 kDa
• Atom Count: 1,797
• Modeled Residue Count: 224
• Deposited Residue Count: 231
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fluorescent protein FP480	A	231	Entacmaea quadricolor	Mutation(s): 0
UniProt
Find proteins for D0VX33 (Entacmaea quadricolor) Explore D0VX33  Go to UniProtKB:  D0VX33

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
NRQ	A	L-PEPTIDE LINKING	C16 H17 N3 O4 S		MET, TYR, GLY

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.41 Å
• R-Value Free:  0.321 (Depositor), 0.332 (DCC)
• R-Value Work:  0.228 (Depositor), 0.221 (DCC)
• R-Value Observed: 0.236 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.394	α = 90
b = 91.394	β = 90
c = 53.525	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-09-08
Deposition Author(s): Pletnev, S., Morozova, K.S., Verkhusha, V.V., Dauter, Z.

Revision History

• Version 1.0: 2009-09-08
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2025-03-26
  Changes: Data collection, Database references, Derived calculations, Structure summary
• Version 2.0: 2026-03-18
  Changes: Polymer sequence
