3GBU | pdb_00003gbu

Crystal structure of an uncharacterized sugar kinase PH1459 from Pyrococcus horikoshii in complex with ATP

• PDB DOI: https://doi.org/10.2210/pdb3GBU/pdb

• Classification: TRANSFERASE
• Organism(s): Pyrococcus horikoshii OT3
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2009-02-20 Released: 2009-03-10
• Deposition Author(s): Eswaramoorthy, S., Kumar, G., Zhang, Z., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:
  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:
  0.216 (Depositor), 0.214 (DCC)
• R-Value Observed:
  0.216 (Depositor)

Starting Model: experimental

Literature

Crystal structure of an uncharacterized sugar kinase PH1459 from Pyrococcus horikoshii in complex with ATP

Eswaramoorthy, S., Kumar, G., Zhang, Z., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 141.27 kDa
• Atom Count: 9,963
• Modeled Residue Count: 1,208
• Deposited Residue Count: 1,252
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized sugar kinase PH1459	A, B, C, D	313	Pyrococcus horikoshii OT3	Mutation(s): 1  Gene Names: PH1459, PHCC008 EC: 2.7.1
UniProt
Find proteins for O59128 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3)) Explore O59128  Go to UniProtKB:  O59128

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ATP	E [auth A], F [auth B], G [auth C], H [auth D]	ADENOSINE-5'-TRIPHOSPHATE C10 H16 N5 O13 P3 ZKHQWZAMYRWXGA-KQYNXXCUSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:  0.216 (Depositor), 0.214 (DCC)
• R-Value Observed: 0.216 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 71.148	α = 90
b = 119.422	β = 90
c = 178.81	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
PHASER	phasing
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-03-10
Deposition Author(s): Eswaramoorthy, S., Kumar, G., Zhang, Z., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-03-10
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Source and taxonomy, Version format compliance
• Version 1.2: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.3: 2021-10-20
  Changes: Database references
• Version 1.4: 2023-09-06
  Changes: Data collection, Refinement description
• Version 1.5: 2023-11-22
  Changes: Data collection
• Version 1.6: 2024-11-20
  Changes: Structure summary
