3GBF | pdb_00003gbf

Phpd with cadmium complexed with hydroethylphosphonate (HEP)

PDB DOI: https://doi.org/10.2210/pdb3GBF/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Streptomyces viridochromogenes
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-02-19 Released: 2009-06-09
Deposition Author(s): Zhang, H., Nair, S.K.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.92 Å
R-Value Free:
0.257 (Depositor), 0.258 (DCC)
R-Value Work:
0.212 (Depositor), 0.211 (DCC)
R-Value Observed:
0.214 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

An Unusual Carbon-Carbon Bond Cleavage Reaction in the Biosynthesis of the Herbicide Phosphinothricin

Cicchillio, R.M., Zhang, H., Blodgett, J.A.V., Whitteck, J.T., Li, G., Nair, S.K., van der Donk, W.A., Metcalf, W.W.

To be published.

Macromolecule Content

Total Structure Weight: 49.97 kDa
Atom Count: 3,453
Modeled Residue Count: 415
Deposited Residue Count: 443
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PhpD	A	443	Streptomyces viridochromogenes	Mutation(s): 0 Gene Names: phpD EC: 1.13.11.72
UniProt
Find proteins for Q5IW40 (Streptomyces viridochromogenes (strain DSM 40736 / JCM 4977 / BCRC 1201 / Tue 494)) Explore Q5IW40 Go to UniProtKB: Q5IW40
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5IW40
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
2HE Query on 2HE Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(2-hydroxyethyl)phosphonic acid C₂ H₇ O₄ P SEHJHHHUIGULEI-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
CD Query on CD Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain M [auth A] SDF format, chain G [auth A] SDF format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain M [auth A] MOL2 format, chain G [auth A] MOL2 format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain M [auth A] mmCIF format, chain G [auth A] mmCIF format, chain D [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A]	CADMIUM ION Cd WLZRMCYVCSSEQC-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.92 Å
R-Value Free: 0.257 (Depositor), 0.258 (DCC)
R-Value Work: 0.212 (Depositor), 0.211 (DCC)
R-Value Observed: 0.214 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.974	α = 90
b = 94.695	β = 90
c = 101.595	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
SHARP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-06-09

Deposition Author(s):

Zhang, H.

Nair, S.K.

Revision History (Full details and data files)

Version 1.0: 2009-06-09
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
