3FUW

T. thermophilus 16S rRNA A1518 and A1519 methyltransferase (KsgA) in complex with 5'-methylthioadenosine in space group P212121


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.197
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structural rearrangements in the active site of the Thermus thermophilus 16S rRNA methyltransferase KsgA in a binary complex with 5'-methylthioadenosine.

Demirci, H.Belardinelli, R.Seri, E.Gregory, S.T.Gualerzi, C.Dahlberg, A.E.Jogl, G.

(2009) J Mol Biol 388: 271-282

  • DOI: https://doi.org/10.1016/j.jmb.2009.02.066
  • Primary Citation of Related Structures:
    3FUT, 3FUU, 3FUV, 3FUW, 3FUX

  • PubMed Abstract:

    Posttranscriptional modification of ribosomal RNA (rRNA) occurs in all kingdoms of life. The S-adenosyl-L-methionine-dependent methyltransferase KsgA introduces the most highly conserved rRNA modification, the dimethylation of A1518 and A1519 of 16S rRNA. Loss of this dimethylation confers resistance to the antibiotic kasugamycin. Here, we report biochemical studies and high-resolution crystal structures of KsgA from Thermus thermophilus. Methylation of 30S ribosomal subunits by T. thermophilus KsgA is more efficient at low concentrations of magnesium ions, suggesting that partially unfolded RNA is the preferred substrate. The overall structure is similar to that of other methyltransferases but contains an additional alpha-helix in a novel N-terminal extension. Comparison of the apoenzyme with complex structures with 5'-methylthioadenosine or adenosine bound in the cofactor-binding site reveals novel features when compared with related enzymes. Several mobile loop regions that restrict access to the cofactor-binding site are observed. In addition, the orientation of residues in the substrate-binding site indicates that conformational changes are required for binding two adjacent residues of the substrate rRNA.


  • Organizational Affiliation

    Department of Molecular Biology, Cell Biology and Biochemistry, Brown University, Box G-L235, Providence, RI 02912, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Dimethyladenosine transferase271Thermus thermophilus HB8Mutation(s): 0
Gene Names: ksgATTHA0083
EC: 2.1.1 (PDB Primary Data), 2.1.1.182 (UniProt)
UniProt
Find proteins for Q5SM60 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SM60
Go to UniProtKB:  Q5SM60
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SM60
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MTA
Query on MTA

Download Ideal Coordinates CCD File
B [auth A]5'-DEOXY-5'-METHYLTHIOADENOSINE
C11 H15 N5 O3 S
WUUGFSXJNOTRMR-IOSLPCCCSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.197
  • R-Value Observed: 0.199
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.417α = 90
b = 61.042β = 90
c = 82.531γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-03-31
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Source and taxonomy, Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Refinement description
  • Version 1.3: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
