3EN2 | pdb_00003en2

Three-dimensional structure of the protein priB from Ralstonia solanacearum at the resolution 2.3A. Northeast Structural Genomics Consortium target RsR213C.

PDB DOI: https://doi.org/10.2210/pdb3EN2/pdb

Classification: structural genomics, unknown function
Organism(s): Ralstonia solanacearum
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2008-09-25 Released: 2008-10-07
Deposition Author(s): Kuzin, A.P., Neely, H., Wang, H., Sahdev, S., Foote, E.L., Xiao, R., Liu, J., Everett, J.K., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.240 (Depositor), 0.251 (DCC)
R-Value Work:
0.225 (Depositor), 0.238 (DCC)
R-Value Observed:
0.225 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3EN2

This is version 1.6 of the entry. See complete history.

Literature

Three-dimensional structure of the protein priB from Ralstonia solanacearum at the resolution 2.3A. Northeast Structural Genomics Consortium target RsR213C.

Kuzin, A.P., Neely, H., Wang, H., Sahdev, S., Foote, E.L., Xiao, R., Liu, J., Everett, J.K., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L.

To be published.

Macromolecule Content

Total Structure Weight: 11.29 kDa
Atom Count: 768
Modeled Residue Count: 91
Deposited Residue Count: 101
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable primosomal replication protein n	A	101	Ralstonia solanacearum	Mutation(s): 1
UniProt
Find proteins for Q8XZT7 (Ralstonia nicotianae (strain ATCC BAA-1114 / GMI1000)) Explore Q8XZT7 Go to UniProtKB: Q8XZT7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8XZT7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
K Query on K Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.240 (Depositor), 0.251 (DCC)
R-Value Work: 0.225 (Depositor), 0.238 (DCC)
R-Value Observed: 0.225 (Depositor)

Space Group: I 4₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.692	α = 90
b = 70.692	β = 90
c = 141.2	γ = 90

Software Package:

Software Name	Purpose
BALBES	phasing
CNS	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-10-07

Deposition Author(s):

Montelione, G.T.

Northeast Structural Genomics Consortium (NESG)

Revision History (Full details and data files)

Version 1.0: 2008-10-07
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2018-01-24
Changes: Database references, Structure summary
Version 1.3: 2021-10-20
Changes: Database references, Derived calculations
Version 1.4: 2023-09-06
Changes: Data collection, Refinement description
Version 1.5: 2023-11-15
Changes: Data collection
Version 1.6: 2024-10-30
Changes: Structure summary
