39NW | pdb_000039nw

The crystal structure of a solute-binding protein (L70F and N280D mutant) from Trichormus variabilis ATCC 29413 in complex with isoleucine.

PDB DOI: https://doi.org/10.2210/pdb39NW/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Trichormus variabilis ATCC 29413
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2026-10-19 Released: 2026-10-28
Deposition Author(s): Tan, K., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free:
0.221 (Depositor), 0.220 (DCC)
R-Value Work:
0.189 (Depositor), 0.189 (DCC)
R-Value Observed:
0.191 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

The crystal structure of a solute-binding protein (L70F and N280D mutant) from Trichormus variabilis ATCC 29413 in complex with isoleucine.

Tan, K., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 85.48 kDa
Atom Count: 6,072
Modeled Residue Count: 728
Deposited Residue Count: 790
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Amino acid/amide ABC transporter substrate-binding protein, HAAT family	A, B	395	Trichormus variabilis ATCC 29413	Mutation(s): 2 Gene Names: Ava_0465
UniProt
Find proteins for Q3MFZ5 (Trichormus variabilis (strain ATCC 29413 / PCC 7937)) Explore Q3MFZ5 Go to UniProtKB: Q3MFZ5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q3MFZ5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ILE (Subject of Investigation/LOI) Query on ILE Download:Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain C [auth A] MOL2 format, chain H [auth B] MOL2 format, chain C [auth A] mmCIF format, chain H [auth B] mmCIF format, chain C [auth A]	C [auth A], H [auth B]	ISOLEUCINE C₆ H₁₃ N O₂ AGPKZVBTJJNPAG-WHFBIAKZSA-N		Interactions Focus chain C [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain G [auth A] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A]	G [auth A], J [auth B], K [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Interactions & Density Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B]
FMT Query on FMT Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain D [auth A] MOL2 format, chain I [auth B] MOL2 format, chain D [auth A] mmCIF format, chain I [auth B] mmCIF format, chain D [auth A]	D [auth A], I [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain I [auth B] Interactions & Density Focus chain D [auth A] Focus chain I [auth B]
