38WE | pdb_000038we

Crystal structure of the CFTR inhibitory factor Cif with the F164A mutation

• PDB DOI: https://doi.org/10.2210/pdb38WE/pdb

• Classification: HYDROLASE
• Organism(s): Pseudomonas aeruginosa UCBPP-PA14
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2026-09-21 Released: 2026-10-07
• Deposition Author(s): Nie, Z., Madden, D.R.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.66 Å
• R-Value Free:
  0.196 (Depositor), 0.196 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.169 (DCC)
• R-Value Observed:
  0.170 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the CFTR inhibitory factor Cif with the F164A mutation

Nie, Z., Madden, D.R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: homology

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: homology

Macromolecule Content

• Total Structure Weight: 133.28 kDa
• Atom Count: 11,152
• Modeled Residue Count: 1,180
• Deposited Residue Count: 1,180
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CFTR inhibitory factor	A, B, C, D	295	Pseudomonas aeruginosa UCBPP-PA14	Mutation(s): 1  Gene Names: cif, PA14_26090 EC: 3.3.2.10
UniProt
Find proteins for A0A0H2ZD27 (Pseudomonas aeruginosa (strain UCBPP-PA14)) Explore A0A0H2ZD27  Go to UniProtKB:  A0A0H2ZD27

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CA	E [auth A], F [auth A], G [auth A], H [auth B], I [auth C], J [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.66 Å
• R-Value Free:  0.196 (Depositor), 0.196 (DCC)
• R-Value Work:  0.169 (Depositor), 0.169 (DCC)
• R-Value Observed: 0.170 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 168.607	α = 90
b = 84.159	β = 100.535
c = 89.306	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing
Coot	model building

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-10-07
Deposition Author(s): Nie, Z., Madden, D.R.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P20-GM113132
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P30-GM165328
National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)	United States	P30-DK117469

Revision History

• Version 1.0: 2026-10-07
  Type: Initial release
