31RU | pdb_000031ru

Crystal structure of PIM1 kinase in complex with compound 20

• PDB DOI: https://doi.org/10.2210/pdb31RU/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2026-06-18 Released: 2026-07-01
• Deposition Author(s): Zhubi, R., Schroeder, M., Kalampaliki, A., Knapp, S., Kraemer, A., Structural Genomics Consortium
• Funding Organization(s): German Research Foundation (DFG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.228 (Depositor), 0.228 (DCC)
• R-Value Work:
  0.195 (Depositor), 0.195 (DCC)
• R-Value Observed:
  0.197 (Depositor)

Starting Model: experimental

Literature

Crystal structure of PIM1 kinase in complex with compound 20

Zhubi, R., Schroeder, M., Kalampaliki, A., Knapp, S., Kraemer, A., Structural Genomics Consortium

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 37.86 kDa
• Atom Count: 2,308
• Modeled Residue Count: 282
• Deposited Residue Count: 327
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein kinase pim-1	A	313	Homo sapiens	Mutation(s): 0  Gene Names: PIM1 EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for P11309 (Homo sapiens) Explore P11309  Go to UniProtKB:  P11309
PHAROS:  P11309 GTEx:  ENSG00000137193

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
ALA-ARG-LYS-ARG-ARG-ARG-HIS-PRO-SER-GLY-PRO-PRO-THR-ALA	B [auth Q]	14	Homo sapiens	Mutation(s): 0

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1KBF( Subject of Investigation/LOI)	C [auth A]	6-chloranyl-3-[4-(1~{H}-indol-3-yl)-1~{H}-pyrazol-5-yl]quinazolin-4-one C19 H12 Cl N5 O SZKXRZQREVWXRK-UHFFFAOYSA-N
SO4	F [auth A], G [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
EDO	D [auth A], E [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.228 (Depositor), 0.228 (DCC)
• R-Value Work:  0.195 (Depositor), 0.195 (DCC)
• R-Value Observed: 0.197 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 96.624	α = 90
b = 96.624	β = 90
c = 80.199	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing
PDB_EXTRACT	data extraction

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-07-01
Deposition Author(s): Zhubi, R., Schroeder, M., Kalampaliki, A., Knapp, S., Kraemer, A., Structural Genomics Consortium

---

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	--

Revision History

• Version 1.0: 2026-07-01
  Type: Initial release
