2ZZO | pdb_00002zzo

Crystal structure of the complex between GP41 fragment N36 and fusion inhibitor C34/S138A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.283 (Depositor), 0.279 (DCC)
  • R-Value Work:
    0.212 (Depositor), 0.208 (DCC)
  • R-Value Observed:
    0.215 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2ZZO

This is version 1.4 of the entry. See complete history

Literature

X-ray crystallographic study of an HIV-1 fusion inhibitor with the gp41 S138A substitution

Watabe, T.Terakawa, Y.Watanabe, K.Ohno, H.Nakano, H.Nakatsu, T.Kato, H.Izumi, K.Kodama, E.Matsuoka, M.Kitaura, K.Oishi, S.Fujii, N.

(2009) J Mol Biology 392: 657-665

  • DOI: https://doi.org/10.1016/j.jmb.2009.07.027
  • Primary Citation Related Structures:
    2ZZO

  • PubMed Abstract:

    The S138A substitution of fusion inhibitory peptides derived from the C-terminal heptad repeat (C-HR) of the human immunodeficiency virus type 1 (HIV-1) gp41 leads to enhanced binding affinity to the N-terminal heptad repeat (N-HR). As such, these peptides exhibit highly potent anti-HIV-1 activity. X-ray crystallographic analysis was performed to understand the effect of the substitution on binding affinity. The comparison of the native and S138A crystal structures indicated that the increase in the hydrophobicity of the S138A substitution may aid the stabilization of the N-HR/C-HR complex through additional hydrophobic contacts. Free-energy calculations suggest that the difference between the desolvation free energies of the C-HR-derived peptides with and without the S138A mutation dominates the observed difference in anti-HIV-1 activity.


  • Organizational Affiliation
    • Kyoto University, Sakyo-ku, Japan.

Macromolecule Content

  • Total Structure Weight: 8.41 kDa
  • Atom Count: 620
  • Modeled Residue Count: 72
  • Deposited Residue Count: 72
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Transmembrane proteinA [auth N]37N/AMutation(s): 1
UniProt
Find proteins for P03377 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI))
Explore P03377
Go to UniProtKB:  P03377
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03377
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Transmembrane proteinB [auth C]35N/AMutation(s): 2
UniProt
Find proteins for P03377 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI))
Explore P03377
Go to UniProtKB:  P03377
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03377
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.283 (Depositor), 0.279 (DCC)
  • R-Value Work:  0.212 (Depositor), 0.208 (DCC)
  • R-Value Observed: 0.215 (Depositor)
Space Group: P 3 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.09α = 90
b = 49.09β = 90
c = 56.4γ = 120
Software Package:
Software NamePurpose
MOLREPphasing
REFMACrefinement
d*TREKdata reduction
d*TREKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-08-04
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-11-10
    Changes: Database references, Derived calculations
  • Version 1.3: 2023-11-01
    Changes: Data collection, Refinement description
  • Version 1.4: 2024-10-16
    Changes: Structure summary
