2XYB

CRYSTAL STRUCTURE OF A FULLY FUNCTIONAL LACCASE FROM THE LIGNINOLYTIC FUNGUS PYCNOPORUS CINNABARINUS

PDB DOI: https://doi.org/10.2210/pdb2XYB/pdb

Classification: OXIDOREDUCTASE
Organism(s): Trametes cinnabarina
Mutation(s): No

Deposited: 2010-11-17 Released: 2011-11-30
Deposition Author(s): Piontek, K., Choinowski, T., Antorini, M., Herpoel-Gimbert, I., Plattner, D.A., Sigoillot, J.C., Asther, M., Winterhalter, K.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.208
R-Value Work: 0.164
R-Value Observed: 0.166

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.2 of the entry. See complete history.

Literature

Substrate Binding and Copper Geometry in Laccases

Piontek, K., Choinowski, T., Antorini, M., Herpoel-Gimbert, I., Asther, M., Plattner, D.A.

To be published.

Macromolecule Content

Total Structure Weight: 58 kDa
Atom Count: 4,791
Modelled Residue Count: 497
Deposited Residue Count: 497
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LACCASE	A	497	Trametes cinnabarina	Mutation(s): 0 EC: 1.10.3.2
UniProt
Find proteins for Q9UVQ2 (Pycnoporus cinnabarinus) Explore Q9UVQ2 Go to UniProtKB: Q9UVQ2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9UVQ2
Glycosylation
Glycosylation Sites: 5	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-6)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	B	4		N-Glycosylation	Interactions Focus chain B Interactions & Density Focus chain B
Glycosylation Resources
GlyTouCan: G22573RC GlyCosmos: G22573RC GlyGen: G22573RC

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, D	2		N-Glycosylation	Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	E	3		N-Glycosylation	Interactions Focus chain E Interactions & Density Focus chain E
Glycosylation Resources
GlyTouCan: G15407YE GlyCosmos: G15407YE GlyGen: G15407YE

Small Molecules

Ligands 9 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
AS8 Query on AS8 Download Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	ACETYLSULFATE C₂ H₄ O₅ S HZWXJJCSDBQVLF-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Interactions & Density Focus chain L [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A]	N [auth A], O [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain N [auth A] Focus chain O [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A]	P [auth A], Q [auth A], R [auth A], S [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Interactions & Density Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain AA [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] SDF format, chain V [auth A] SDF format, chain W [auth A] SDF format, chain X [auth A] SDF format, chain Y [auth A] SDF format, chain Z [auth A] MOL2 format, chain AA [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] MOL2 format, chain V [auth A] MOL2 format, chain W [auth A] MOL2 format, chain X [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain Z [auth A] mmCIF format, chain AA [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A] mmCIF format, chain V [auth A] mmCIF format, chain W [auth A] mmCIF format, chain X [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain Z [auth A]	AA [auth A] T [auth A] U [auth A] V [auth A] W [auth A] AA [auth A], T [auth A], U [auth A], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain AA [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]
CU Query on CU Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A]	F [auth A], G [auth A], H [auth A], I [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
ACT Query on ACT Download Ideal Coordinates CCD File SDF format, chain M [auth A] MOL2 format, chain M [auth A] mmCIF format, chain M [auth A]	M [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain M [auth A] Interactions & Density Focus chain M [auth A]
PER Query on PER Download Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	PEROXIDE ION O₂ ANAIPYUSIMHBEL-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain BA [auth A] MOL2 format, chain BA [auth A] mmCIF format, chain BA [auth A]	BA [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain BA [auth A] Interactions & Density Focus chain BA [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.208
R-Value Work: 0.164
R-Value Observed: 0.166
Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 145.296	α = 90
b = 62.902	β = 126.7
c = 91.416	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
AMoRE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2011-11-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2011-11-30
Type: Initial release
Version 1.1: 2019-07-17
Changes: Data collection
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Derived calculations, Other, Structure summary
Version 2.1: 2023-12-20
Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
Version 2.2: 2024-10-16
Changes: Structure summary
