2XWY | pdb_00002xwy

Structure of MK-3281, a Potent Non-Nucleoside Finger-Loop Inhibitor, in complex with the Hepatitis C Virus NS5B Polymerase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free:
    0.310 (Depositor), 0.301 (DCC)
  • R-Value Work:
    0.233 (Depositor), 0.230 (DCC)
  • R-Value Observed:
    0.237 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2XWY

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Discovery of (7R)-14-Cyclohexyl-7-{[2-(Dimethylamino)Ethyl] (Methyl)Amino}-7,8-Dihydro-6H-Indolo[1,2-E][1,5] Benzoxazocine -11-Carboxylic Acid (Mk-3281), a Potent and Orally Bioavailable Finger-Loop Inhibitor of the Hepatitis C Virus Ns5B Polymerase

Narjes, F.Crescenzi, B.Ferrara, M.Habermann, J.Colarusso, S.Del Rosario Rico Ferreira, M.Stansfield, I.Mackay, A.C.Conte, I.Ercolani, C.Zaramella, S.Palumbi, M.C.Meuleman, P.Leroux-Roels, G.Giuliano, C.Fiore, F.Di Marco, S.Baiocco, P.Koch, U.Migliaccio, G.Altamura, S.Laufer, R.De Francesco, R.Rowley, M.

(2011) J Med Chem 54: 289

  • DOI: https://doi.org/10.1021/jm1013105
  • Primary Citation Related Structures:
    2XWY

  • PubMed Abstract:

    Infections caused by hepatitis C virus (HCV) are a significant world health problem for which novel therapies are in urgent demand. The polymerase of HCV is responsible for the replication of viral genome and has been a prime target for drug discovery efforts. Here, we report on the further development of tetracyclic indole inhibitors, binding to an allosteric site on the thumb domain. Structure-activity relationship (SAR) studies around an indolo-benzoxazocine scaffold led to the identification of compound 33 (MK-3281), an inhibitor with good potency in the HCV subgenomic replication assay and attractive molecular properties suitable for a clinical candidate. The compound caused a consistent decrease in viremia in vivo using the chimeric mouse model of HCV infection.


  • Organizational Affiliation
    • Istituto Di Ricerche Di Biologia Molecolare, P. Angeletti SpA (Merck Research Laboratories, Rome), Pomezia, Italy. Frank.Narjes@astrazeneca.com

Macromolecule Content

  • Total Structure Weight: 60.36 kDa
  • Atom Count: 4,078
  • Modeled Residue Count: 507
  • Deposited Residue Count: 537
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA-DIRECTED RNA POLYMERASE537Orthohepacivirus hominisMutation(s): 0
EC: 2.7.7.48
UniProt
Find proteins for P26663 (Hepatitis C virus genotype 1b (isolate BK))
Explore P26663
Go to UniProtKB:  P26663
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26663
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
IB8

Query on IB8



Download:Ideal Coordinates CCD File
B [auth A](7R)-14-cyclohexyl-7-{[2-(dimethylamino)ethyl](methyl)amino}-7,8-dihydro-6H-indolo[1,2-e][1,5]benzoxazocine-11-carboxylic acid
C29 H37 N3 O3
YQUCBFIQSJVCOR-JOCHJYFZSA-N
MN

Query on MN



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free:  0.310 (Depositor), 0.301 (DCC)
  • R-Value Work:  0.233 (Depositor), 0.230 (DCC)
  • R-Value Observed: 0.237 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.983α = 90
b = 94.272β = 90
c = 95.145γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-12-22
    Type: Initial release
  • Version 1.1: 2011-10-26
    Changes: Database references, Version format compliance
  • Version 1.2: 2019-04-03
    Changes: Data collection, Experimental preparation, Other
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
