2VWS | pdb_00002vws

Crystal structure of YfaU, a metal ion dependent class II aldolase from Escherichia coli K12


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.39 Å
  • R-Value Free:
    0.191 (Depositor), 0.190 (DCC)
  • R-Value Work:
    0.171 (Depositor), 0.171 (DCC)
  • R-Value Observed:
    0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2VWS

This is version 1.2 of the entry. See complete history

Literature

Crystal Structure and Functional Assignment of Yfau, a Metal Ion Dependent Class II Aldolase from Escherichia Coli K12.

Rea, D.Hovington, R.Rakus, J.F.Gerlt, J.A.Fulop, V.Bugg, T.D.H.Roper, D.I.

(2008) Biochemistry 47: 9955

  • DOI: https://doi.org/10.1021/bi800943g
  • Primary Citation Related Structures:
    2VWS, 2VWT

  • PubMed Abstract:

    One of the major challenges in the postgenomic era is the functional assignment of proteins using sequence- and structure-based predictive methods coupled with experimental validation. We have used these approaches to investigate the structure and function of the Escherichia coli K-12 protein YfaU, annotated as a putative 4-hydroxy-2-ketoheptane-1,7-dioate aldolase (HpcH) in the sequence databases. HpcH is the final enzyme in the degradation pathway of the aromatic compound homoprotocatechuate. We have determined the crystal structure of apo-YfaU and the Mg (2+)-pyruvate product complex. Despite greater sequence and structural similarity to HpcH, genomic context suggests YfaU is instead a 2-keto-3-deoxy sugar aldolase like the homologous 2-dehydro-3-deoxygalactarate aldolase (DDGA). Enzyme kinetic measurements show activity with the probable physiological substrate 2-keto-3-deoxy- l-rhamnonate, supporting the functional assignment, as well as the structurally similar 2-keto-3-deoxy- l-mannonate and 2-keto-3-deoxy- l-lyxonate (see accompanying paper: Rakus, J. F., Fedorov, A. A., Fedorov, E. V., Glasner, M. E., Hubbard, B. K., Delli, J. D., Babbitt, P. C., Almo, S. C., and Gerlt, J. A. (2008) Biochemistry 47, 9944-9954). YfaU has similar activity toward the HpcH substrate 4-hydroxy-2-ketoheptane-1,7-dioate and synthetic substrates 4-hydroxy-2-ketopentanoic acid and 4-hydroxy-2-ketohexanoic acid. This indicates a relaxed substrate specificity that complicates the functional assignment of members of this enzyme superfamily. Crystal structures suggest these enzymes use an Asp-His intersubunit dyad to activate a metal-bound water or hydroxide for proton transfer during catalysis.


  • Organizational Affiliation
    • Department of Biological Sciences, University of Warwick, Gibbet Hill Road, Coventry, UK.

Macromolecule Content

  • Total Structure Weight: 87.39 kDa
  • Atom Count: 6,845
  • Modeled Residue Count: 768
  • Deposited Residue Count: 801
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
YFAU, 2-KETO-3-DEOXY SUGAR ALDOLASE
A, B, C
267Escherichia coli K-12Mutation(s): 0
EC: 4.1.2.20 (PDB Primary Data), 4.1.2.53 (UniProt)
UniProt
Find proteins for P76469 (Escherichia coli (strain K12))
Explore P76469
Go to UniProtKB:  P76469
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP76469
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.39 Å
  • R-Value Free:  0.191 (Depositor), 0.190 (DCC)
  • R-Value Work:  0.171 (Depositor), 0.171 (DCC)
  • R-Value Observed: 0.172 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.2α = 90
b = 136.8β = 90
c = 123.2γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-09-09
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.2: 2023-12-13
    Changes: Data collection, Database references, Other, Refinement description
