2R8B | pdb_00002r8b

The crystal structure of the protein Atu2452 of unknown function from Agrobacterium tumefaciens str. C58

PDB DOI: https://doi.org/10.2210/pdb2R8B/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Agrobacterium fabrum str. C58
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2007-09-10 Released: 2007-09-25
Deposition Author(s): Tan, K., Xu, X., Zheng, H., Savchenko, A., Edwards, A.M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.56 Å
R-Value Free:
0.253 (Depositor), 0.232 (DCC)
R-Value Work:
0.194 (Depositor)
R-Value Observed:
0.197 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2R8B

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of the protein Atu2452 of unknown function from Agrobacterium tumefaciens str. C58.

Tan, K., Xu, X., Zheng, H., Savchenko, A., Edwards, A.M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 54.98 kDa
Atom Count: 3,135
Modeled Residue Count: 408
Deposited Residue Count: 502
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein Atu2452	A, B	251	Agrobacterium fabrum str. C58	Mutation(s): 0 Gene Names: AGR_C_4453, Atu2452
UniProt
Find proteins for A9CHT9 (Agrobacterium fabrum (strain C58 / ATCC 33970)) Explore A9CHT9 Go to UniProtKB: A9CHT9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A9CHT9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.56 Å
R-Value Free: 0.253 (Depositor), 0.232 (DCC)
R-Value Work: 0.194 (Depositor)
R-Value Observed: 0.197 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.904	α = 90
b = 58.727	β = 90
c = 165.155	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
MLPHARE	phasing
DM	phasing
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-09-25

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2007-09-25
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.2: 2024-11-13
Changes: Data collection, Database references, Derived calculations, Structure summary
