2QU1 | pdb_00002qu1

Crystal Structure of a Cyclized GFP Variant

PDB DOI: https://doi.org/10.2210/pdb2QU1/pdb

Classification: LUMINESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2007-08-03 Released: 2007-09-11
Deposition Author(s): Bailey, L.J., McCoy, J.G., Bitto, E., Bingman, C.A., Fox, B.G., Wesenberg, G.E., Phillips Jr., G.N., Center for Eukaryotic Structural Genomics (CESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.220 (Depositor), 0.224 (DCC)
R-Value Work:
0.168 (Depositor), 0.172 (DCC)
R-Value Observed:
0.171 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2QU1

This is version 2.0 of the entry. See complete history.

Literature

Crystal Structure of a Cyclized GFP Variant.

Bailey, L.J., McCoy, J.G., Bitto, E., Bingman, C.A., Fox, B.G., Wesenberg, G.E., Phillips Jr., G.N.

To be published.

Macromolecule Content

Total Structure Weight: 27.29 kDa
Atom Count: 2,293
Modeled Residue Count: 232
Deposited Residue Count: 239
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Green fluorescent protein	A	239	Aequorea victoria	Mutation(s): 5 Gene Names: GFP
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRO Query on CRO	A	L-PEPTIDE LINKING	C₁₅ H₁₇ N₃ O₅		THR, TYR, GLY
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.220 (Depositor), 0.224 (DCC)
R-Value Work: 0.168 (Depositor), 0.172 (DCC)
R-Value Observed: 0.171 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.46	α = 90
b = 61.99	β = 90
c = 70.02	γ = 90

Software Package:

Software Name	Purpose
SAINT	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
PROTEUM PLUS	data collection
SAINT	data reduction
SADABS	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-09-11

Deposition Author(s):

Wesenberg, G.E.

Phillips Jr., G.N.

Center for Eukaryotic Structural Genomics (CESG)

Revision History (Full details and data files)

Version 1.0: 2007-09-11
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2021-10-20
Changes: Database references, Derived calculations
Version 1.3: 2023-08-30
Changes: Data collection, Refinement description
Version 1.4: 2023-11-15
Changes: Data collection
Version 1.5: 2024-10-30
Changes: Structure summary
Version 2.0: 2026-03-18
Changes: Polymer sequence
