2QJ8 | pdb_00002qj8

Crystal structure of an aspartoacylase family protein (mlr6093) from mesorhizobium loti maff303099 at 2.00 A resolution

PDB DOI: https://doi.org/10.2210/pdb2QJ8/pdb

Classification: HYDROLASE
Organism(s): Mesorhizobium japonicum MAFF 303099
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2007-07-06 Released: 2007-07-24
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.254 (Depositor), 0.258 (DCC)
R-Value Work:
0.207 (Depositor), 0.209 (DCC)
R-Value Observed:
0.209 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2QJ8

This is version 1.6 of the entry. See complete history.

Literature

Crystal structure of uncharacterized protein mlr6093 (NP_106651.1) from Mesorhizobium loti at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 72.06 kDa
Atom Count: 4,945
Modeled Residue Count: 603
Deposited Residue Count: 664
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mlr6093 protein	A, B	332	Mesorhizobium japonicum MAFF 303099	Mutation(s): 6 Gene Names: NP_106651.1, mlr6093
UniProt
Find proteins for Q98AA0 (Mesorhizobium japonicum (strain LMG 29417 / CECT 9101 / MAFF 303099)) Explore Q98AA0 Go to UniProtKB: Q98AA0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q98AA0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.254 (Depositor), 0.258 (DCC)
R-Value Work: 0.207 (Depositor), 0.209 (DCC)
R-Value Observed: 0.209 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.054	α = 90
b = 86.14	β = 90
c = 94.632	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
ADSC	data collection
MOSFLM	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-07-24

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2007-07-24
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.3: 2017-10-18
Changes: Refinement description
Version 1.4: 2019-07-24
Changes: Data collection, Derived calculations, Refinement description
Version 1.5: 2023-01-25
Changes: Database references
Version 1.6: 2024-10-30
Changes: Data collection, Refinement description, Structure summary
