2O7Q | pdb_00002o7q

Crystal Structure of the A. thaliana DHQ-dehydroshikimate-SDH-shikimate-NADP(H)

• PDB DOI: https://doi.org/10.2210/pdb2O7Q/pdb

• Classification: OXIDOREDUCTASE,TRANSFERASE
• Organism(s): Arabidopsis thaliana
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2006-12-11 Released: 2007-11-20
• Deposition Author(s): Christendat, D., Singh, S.A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:
  0.214 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.218 (DCC)
• R-Value Observed:
  0.259 (Depositor)

Literature

The DHQ-dehydroshikimate-SDH-shikimate-NADP(H) Complex: Insights into Metabolite Transfer in the Shikimate Pathway

Singh, S.A., Christendat, D.

(2007) Cryst Growth Des 7: 2153-2160

• DOI: https://doi.org/10.1021/cg7007107

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PQS (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 57.76 kDa
• Atom Count: 4,066
• Modeled Residue Count: 501
• Deposited Residue Count: 523
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bifunctional 3-dehydroquinate dehydratase/shikimate dehydrogenase	A	523	Arabidopsis thaliana	Mutation(s): 2  Gene Names: EMB3004 EC: 1.1.1.25 (PDB Primary Data), 4.2.1.10 (PDB Primary Data)
UniProt
Find proteins for Q9SQT8 (Arabidopsis thaliana) Explore Q9SQT8  Go to UniProtKB:  Q9SQT8

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
DHK	E [auth A], F [auth A]	3-DEHYDROSHIKIMATE C7 H10 O5 YVYKOQWMJZXRRM-UYFOZJQFSA-N
SO4	B [auth A], C [auth A], D [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSO	A	L-PEPTIDE LINKING	C3 H7 N O3 S		CYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:  0.214 (Depositor), 0.260 (DCC)
• R-Value Work:  0.218 (DCC)
• R-Value Observed: 0.259 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 96.611	α = 90
b = 96.611	β = 90
c = 115.945	γ = 120

Software Package:

Software Name	Purpose
HKL-3000	data collection
SOLVE	phasing
CNS	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-11-20
Deposition Author(s): Christendat, D., Singh, S.A.

Revision History

• Version 1.0: 2007-11-20
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Derived calculations, Version format compliance
• Version 1.2: 2023-12-27
  Changes: Data collection, Database references, Derived calculations
• Version 1.3: 2024-10-30
  Changes: Structure summary
