2MYA | pdb_00002mya

HIGH RESOLUTION X-RAY STRUCTURES OF MYOGLOBIN-AND HEMOGLOBIN-ALKYL ISOCYANIDE COMPLEXES

• PDB DOI: https://doi.org/10.2210/pdb2MYA/pdb

• Classification: OXYGEN STORAGE
• Organism(s): Physeter macrocephalus
• Mutation(s): No


• Deposited: 1993-08-04 Released: 1994-01-31
• Deposition Author(s): Johnson, K.A., Olson, J.S., Phillips Jr., G.N.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Work:
  0.178 (Depositor)
• R-Value Observed:
  0.178 (Depositor)

Literature

High Resolution X-Ray Structures of Myoglobin-and Hemoglobin-Alkyl Isocyanide Complexes

Johnson, K.A.

(1993) Thesis

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 18 kDa
• Atom Count: 1,430
• Modelled Residue Count: 153
• Deposited Residue Count: 153
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MYOGLOBIN (ETHYL ISOCYANIDE)	A	153	Physeter macrocephalus	Mutation(s): 0  EC: 1.11.1 (UniProt), 1.7 (UniProt)
UniProt
Find proteins for P02185 (Physeter macrocephalus) Explore P02185  Go to UniProtKB:  P02185

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	C [auth A]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
SO4	B [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
ENC	D [auth A]	ETHYL ISOCYANIDE C3 H6 N JEGVKBYNUPNGJU-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Work:  0.178 (Depositor)
• R-Value Observed: 0.178 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.64	α = 90
b = 30.95	β = 106.08
c = 34.95	γ = 90

Software Package:

Software Name	Purpose
X-PLOR	model building
X-PLOR	refinement
X-PLOR	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 1994-01-31
Deposition Author(s): Johnson, K.A., Olson, J.S., Phillips Jr., G.N.

Revision History

• Version 1.0: 1994-01-31
  Type: Initial release

• Version 1.1: 2008-03-24
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2024-02-21
  Changes: Data collection, Database references, Derived calculations, Other
